XBR-49/55/65/75X900E
DISASSEMBLY
2-16. HARNESS ASSY (MAIN) AND WLAN/BT MODULE(11AC)
2. XBR-65X900E
116
1 2 3
2 screws (SCREW, +PSW M3X6) P/N: 4-472-518-11
HARNESS ASSY (MAIN)
P/N: 1-910-112-08
WLAN/BT MODULE(11AC)
