XBR-49/55/65/75X900E
DISASSEMBLY
4-2. BADGE, XBR LOGO(H3.7)
4. XBR-75X900E
143
1 2 3
COVER, CARD (2L SBT)
4-3. COVER, CARD (2L SBT)
BADGE, XBR LOGO(H3.7)
P/N: 4-535-586-02
