XBR-49/55/65/75X900E
DISASSEMBLY
2-19. BRACKET, DC JACK (SBT) AND JK
2. XBR-65X900E
119
1 2
3 4 5 6
4 screws (SCREW, +PSW M3X6) P/N: 4-472-518-11
BRACKET, DC JACK (SBT)
JK
