XBR-49/55/65/75X900E
DISASSEMBLY
2-14. SMART CORE (S)
2. XBR-65X900E
114
1 2 3 4
NOTE:
2 screws (SCREW, +PSW M3X6) P/N: 4-472-518-11
SMART CORE (S)
