XBR-49/55/65/75X900E
DISASSEMBLY
1-25. BRACKET, IR IN AND IR (UC2 ONLY)
1. XBR-55X900E
88
5 6 8
NOTE:
7
Screw (SCREW, +PSW M3X6) P/N: 4-472-518-11
BRACKET, IR IN
IR
