XBR-49/55/65/75X900E
DISASSEMBLY
2-34. SHIELD, T-CON (SBT)
2. XBR-65X900E
135
2 screws (SCREW, +PSW M3X6) P/N: 4-472-518-11
4 screws (SCREW M3X2.7 (SBT)) P/N: 4-690-476-01
SHIELD, T-CON (SBT)
1
2
<Sequence Information>
<Sequence Information>
3
