XBR-49/55/65/75X900E
DISASSEMBLY
4-5. AC COVER AND POWER-SUPPLY CORD (WITH CONN.)
4. XBR-75X900E
145
1
Screw (SCREW M3X3.0 STEP) P/N: 4-579-926-01
2 3
4 5 6
POWER-SUPPLY CORD (WITH CONN.)
AC COVER
