XBR-49/55/65/75X900E
DISASSEMBLY
4-10. SP-BOX ASSY, W25XL-R CH-ND
4. XBR-75X900E
150
1
3 2
2 screws (SCREW, +PSW M3X6 W12) P/N: 4-256-393-12
SP-BOX ASSY, W25XL-R CH-ND
