XBR-49/55/65/75X900E
DISASSEMBLY
4-15. SMART CORE (S)
4. XBR-75X900E
155
2 screws (SCREW, +PSW M3X6) P/N: 4-472-518-11
1 2 3 4
NOTE:
SMART CORE (S)
