XBR-49/55/65/75X900E
DISASSEMBLY
4-36. BRACKET, SPEAKER (3L SBT) A
4. XBR-75X900E
177
1
2
8 screws (SCREW, +PSW M3X6) P/N: 4-472-518-11
< R SIDE > < L SIDE >
3
BRACKET, SPEAKER (3L SBT) A
L/R symmetry L/R symmetry
