XBR-49/55/65/75X900E
DISASSEMBLY
5-9. TAPE AND WIRE DRESSING AND SP-BOX ASSY, FY17 W25SMALL-ER
5. XBR-49X900E
189
NOTE:
1
2 3 4
TAPE
TAPE
5
SP-BOX ASSY, FY17 W25SMALL-ER
