XBR-49/55/65/75X900E
DISASSEMBLY
5-29. BRACKET, VESA (MIA)
5. XBR-49X900E
210
1
BRACKET, VESA (MIA)
1
2 3 4
Screw (SCREW, +PSW M4X8) P/N: 2-580-600-01
