XBR-49/55/65/75X900E
DISASSEMBLY
5-35. SHEET, THERMAL(BM) AND E-T-CON (49)
5. XBR-49X900E
216
3 4 5
SHEET, THERMAL(BM)
3 screws (SCREW, +PSW M3X6) P/N: 4-472-518-11
1 2
E-T-CON (49)
FFC (49/55/65)
