XBR-49/55/65/75X900E
EXPLODED VIEWS
CONNECTORS
2. XBR-65X900E
226
REF.NO. PART No. DESCRIPTION MARK
301 1-849-887-11 FLEXIBLE FLAT CABLE 41P CN4400(BMKS)-U2(TCON)(1)
302 1-849-892-11 FLEXIBLE FLAT CABLE 51P CN4401(BMKS)-U1(TCON)(1)
303 1-910-112-07 FLEXIBLE FLAT CABLE 30P CN4000(BMKS)-CN4000(LD)(1)
304 1-910-112-08 HARNESS ASSY (MAIN) CN1000(BMKS)-KEY-WIFI-HSC3L-TSA-CN1002(BMKS)-CN3201(BMKS)-SP(1)
305 1-910-112-09 CONNECTOR ASSY 30P CN400(BMKS)-CON3(TCON)-CN1000(LD)-JK(1)
301
302 303 304 305
