XBR-49/55/65/75X900E
DISASSEMBLY
1-7. SP-BOX ASSY, FY17 W25LARGE-EL
1. XBR-55X900E
69
1
Screw (SCREW, +PSW M3X6 W12) P/N: 4-256-393-12
3 2
SP-BOX ASSY, FY17 W25LARGE-EL
