XBR-49/55/65/75X900E
DISASSEMBLY
1-19. BRACKET, DC JACK (SBT) AND JK3
1. XBR-55X900E
1 2
81
3 4 5 6
BRACKET, DC JACK (SBT)
JK3
4 screws (SCREW, +PSW M3X6) P/N: 4-472-518-11
