XBR-49/55/65/75X900E
DISASSEMBLY
1-35. FFC (49/55/65) AND GASKET, TCON CN (CRN) AND SHEET, THERMAL(BM)
1. XBR-55X900E
98
FFC (49/55/65)
GASKET, TCON CN (CRN) SHEET, THERMAL(BM)
1
2 3
