Sony HAP-S1 User Manual

: EXT port of the HDD AUDIO PLAYER
: External CD drive
[25] Connections
Connecting headphones
You can connect headphones to the PHONES jack on the front panel of the HDD AUDIO
PLAYER.
Note
When headphones are connected, no sound is output from the speakers.
Connect headphones to the PHONES jack on the front panel of the HDD AUDIO PLAYER as
shown below.
When using headphones, insert the plug of the headphones fully. If the plug is not inserted
firmly, this may cause problems such as no sound being output or malfunctions.
: PHONES jack of the HDD AUDIO PLAYER
: Headphones
[26] Network connections (wired LAN)
Required network environment
You can transfer audio files from your computer to the HDD AUDIO PLAYER by connecting
both to the same network, either by a wired or wireless connection.
Confirm the supported environment described below.
Note
You need to connect the HDD AUDIO PLAYER to a network that can access the Internet if
you want to listen to Internet radio programs (*).

Sony HAP-S1 Specifications

General

Product color	Silver
Audio formats supported	AAC, AIFF, ALAC, FLAC, LPCM, MP3, WAV, WMA
Impedance	16 Ω
Frequency range	10 - 100000 Hz
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Channels quantity	2 channels
Wi-Fi	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Automatic synchronization	You don't have to change personal settings when first connecting your device. Your device is automatically synchronized with the settings of your car, so once you have done it for the car, that's it!
Storage media type	HDD
Total storage capacity	500 GB
HDCP	No
Headphone outputs	1
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Display diagonal	4.3 \

Weight and Dimensions

Width	- mm
Weight	- g
