Sony HAP-S1 User Manual

[76] Specifications/Notes
Design and specifications
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC DISTORTION (for the USA and
Canada only):
With 4 ohm loads, both channels driven, from 20 - 20,000 Hz; rated 32 watts per channel
minimum RMS power, with no more than 10% total harmonic distortion from 250 milliwatts to
rated output.
Amplifier section
POWER OUTPUT (models except for China): 40 W + 40 W (4 ohms, 1 kHz, THD 10%)
POWER OUTPUT (models for China): 38 W + 38 W (4 ohms, 1 kHz, THD 10%)
Rated Power Output (models except for China): 35 W + 35 W (4 ohms, 1 kHz, THD 0.9%)
Speaker impedance match: 4 ohms - 16 ohms
S/N ratio: 100 dB (20 kHz LPF, A Network)
Frequency response: 10 Hz - 100 kHz (+0 dB, –3 dB) (4 ohms, LINE IN)
Network section
Wired LAN
1000BASE-T/100BASE-TX/10BASE-T
Wireless LAN
Compatible standards: IEEE 802.11 b/g/n
Frequency band/channel: 2.4 GHz band, channels 1-11 (models for the USA and Canada),
channels 1-13 (models for Europe)
HDD section
Capacity
500 GB (*)
*
Some portions of the capacity are used for data management. Therefore, the capacity a user can
use is less than 500 GB.
Supported playback format
DSD (DSF, DSDIFF), LPCM (WAV, AIFF), FLAC, ALAC, ATRAC Advanced Lossless, ATRAC,
MP3, AAC, WMA (2 channels)

Sony HAP-S1 Specifications

General

Product color	Silver
Audio formats supported	AAC, AIFF, ALAC, FLAC, LPCM, MP3, WAV, WMA
Impedance	16 Ω
Frequency range	10 - 100000 Hz
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Channels quantity	2 channels
Wi-Fi	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Automatic synchronization	You don't have to change personal settings when first connecting your device. Your device is automatically synchronized with the settings of your car, so once you have done it for the car, that's it!
Storage media type	HDD
Total storage capacity	500 GB
HDCP	No
Headphone outputs	1
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Display diagonal	4.3 \

Weight and Dimensions

Width	- mm
Weight	- g
