Sony HAP-S1 User Manual

Jack section
Input section
COAXIAL IN
Input impedance: 75 ohms
Supported playback format: LPCM 2ch
Sampling frequency: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz
Quantization bits: 16 bits, 24 bits
OPTICAL IN
Supported playback format: LPCM 2ch
Sampling frequency: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Quantization bits: 16 bits, 24 bits
LINE IN 1, 2
Input sensitivity: 500 mV
Input impedance: 100 kilohms
Output section
Output jacks
LINE OUT
Output impedance: 2.2 kilohms
2 Hz - 80 kHz (–3 dB)
PHONES (headphone jack)
Stereo jack: 8 ohms or higher
EXT port
Type A USB, Hi-Speed USB
General and others
Power requirements
Models for the USA and Canada: AC 120 V 60 Hz
Models for Europe: AC 230 V 50/60 Hz
Models for China: AC 220 V 50 Hz
Power consumption
Models for the USA and Canada
On: 80 W
During standby mode (when [Network Standby] is set to [Off]): 0.3 W
During standby mode (when [Network Standby] is set to [On] and a wired LAN is used): 2.6 W
During standby mode (when [Network Standby] is set to [On] and a wireless LAN is used): 2.8

Sony HAP-S1 Specifications

General

Product color	Silver
Audio formats supported	AAC, AIFF, ALAC, FLAC, LPCM, MP3, WAV, WMA
Impedance	16 Ω
Frequency range	10 - 100000 Hz
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Channels quantity	2 channels
Wi-Fi	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Automatic synchronization	You don't have to change personal settings when first connecting your device. Your device is automatically synchronized with the settings of your car, so once you have done it for the car, that's it!
Storage media type	HDD
Total storage capacity	500 GB
HDCP	No
Headphone outputs	1
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Display diagonal	4.3 \

Weight and Dimensions

Width	- mm
Weight	- g
