Sony HBD-E280 - Front Panel Assembly Disassembly; BD Drive (BPX-6) Disassembly

HBD-E280/T28
13
2-6. BD DRIVE (BPX-6)
5 three screws
(BV3)
4 tapping screw
8 sound sheet
9 BD drive (BPX-6)
1 wire (flat type) (45 core) (CN1301)
2 wire (flat type) (9 core) (CN2460)
3 wire (flat type) (5 core) (CN2470)
7
6 boss
Note:
When you install the BD
drive (BPX-6), please match
the position of the boss two
places.
2-5. FRONT PANEL ASSY
1 three screws
(BV3)
3 front panel assy
2 five claws
