80
HBD-E280/T28
SECTION 7
ELECTRICAL PARTS LIST
A-1801-264-A AMP BOARD, COMPLETE
********************
< CAPACITOR >
C3003 1-100-905-11 CERAMIC CHIP 0.001uF 10% 50V
C3011 1-165-726-31 ELECT 56uF 20% 16V
C3012 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3013 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3014 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3015 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3016 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3017 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3020 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3021 1-165-726-31 ELECT 56uF 20% 16V
C3022 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3023 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3024 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3025 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3026 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3027 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3030 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3031 1-165-726-31 ELECT 56uF 20% 16V
C3032 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3033 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3034 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3035 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3036 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3037 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3040 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3051 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C3052 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C3054 1-126-933-11 ELECT 100uF 20% 16V
C3055 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C3056 1-126-923-91 ELECT 220uF 20% 10V
C3057 1-112-777-11 CERAMIC CHIP 0.01uF 10% 25V
C3058 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C3060 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C3073 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3091 1-126-934-11 ELECT 220uF 20% 16V
C3099 1-136-165-00 FILM 0.1uF 5% 50V
C3101 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C3102 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C3103 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C3104 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C3105 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C3106 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C3107 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C3108 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3109 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3110 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C3111 1-112-246-11 ELECT 100uF 20% 35V
C3112 1-112-246-11 ELECT 100uF 20% 35V
C3113 1-131-704-11 FILM 1uF 5% 50V
C3114 1-131-704-11 FILM 1uF 5% 50V
C3115 1-112-831-31 ELECT 2200uF 20% 35V
C3116 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3117 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C3118 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3119 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3120 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C3121 1-112-246-11 ELECT 100uF 20% 35V
C3122 1-112-246-11 ELECT 100uF 20% 35V
C3123 1-131-704-11 FILM 1uF 5% 50V
C3124 1-131-704-11 FILM 1uF 5% 50V
C3125 1-112-831-31 ELECT 2200uF 20% 35V
C3126 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3127 1-114-869-11 CERAMIC CHIP 2.2uF 10% 6.3V
C3128 1-114-869-11 CERAMIC CHIP 2.2uF 10% 6.3V
C3201 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C3202 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C3203 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C3204 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C3205 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C3206 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C3207 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C3208 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3209 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3210 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C3211 1-112-246-11 ELECT 100uF 20% 35V
C3212 1-112-246-11 ELECT 100uF 20% 35V
C3213 1-131-704-11 FILM 1uF 5% 50V
C3214 1-131-704-11 FILM 1uF 5% 50V
C3215 1-112-831-31 ELECT 2200uF 20% 35V
C3216 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AMP
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
AUS : Australian model
CND : Canadian model
IT : Italian model
MX : Mexican model
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce por-
tant le numéro spécifi é.
The components identifi ed by mark 9 con-
tain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Les composants identifi és par la marque
9 contiennent des informations confi den-
tielles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est remplacé
et / ou réparé.
Note: When the AMP board is replaced, spread the compound referring to “NOTE OF REPLAC-
ING THE IC3100, IC3200 AND IC3300 ON THE AMP BOARD AND THE COMPLETE
AMP BOARD” on servicing notes (page 9).
Ver. 1.1
