Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-E280/T28
82
R3031 1-218-949-11 METAL CHIP 470 5% 1/16W
R3032 1-218-949-11 METAL CHIP 470 5% 1/16W
R3033 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3034 1-216-801-11 METAL CHIP 22 5% 1/10W
R3035 1-216-805-11 METAL CHIP 47 5% 1/10W
R3037 1-216-805-11 METAL CHIP 47 5% 1/10W
R3040 1-218-990-81 SHORT CHIP 0
R3041 1-218-990-81 SHORT CHIP 0
R3042 1-218-990-81 SHORT CHIP 0
R3043 1-218-990-81 SHORT CHIP 0
R3044 1-218-990-81 SHORT CHIP 0
R3045 1-218-990-81 SHORT CHIP 0
R3050 1-218-937-11 METAL CHIP 47 5% 1/16W
R3051 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3052 1-218-989-11 METAL CHIP 1M 5% 1/16W
R3053 1-218-945-11 METAL CHIP 220 5% 1/16W
R3054 1-218-943-11 METAL CHIP 150 5% 1/16W
R3055 1-218-937-11 METAL CHIP 47 5% 1/16W
R3057 1-218-937-11 METAL CHIP 47 5% 1/16W
R3059 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3060 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3063 1-218-941-81 METAL CHIP 100 5% 1/16W
R3065 1-216-809-11 METAL CHIP 100 5% 1/10W
R3067 1-216-809-11 METAL CHIP 100 5% 1/10W
R3072 1-216-805-11 METAL CHIP 47 5% 1/10W
R3073 1-216-805-11 METAL CHIP 47 5% 1/10W
R3074 1-216-805-11 METAL CHIP 47 5% 1/10W
R3103 1-218-969-11 METAL CHIP 22K 5% 1/16W
R3107 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3108 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3109 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3110 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3111 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3112 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3131 1-216-805-11 METAL CHIP 47 5% 1/10W
R3132 1-216-805-11 METAL CHIP 47 5% 1/10W
R3133 1-216-805-11 METAL CHIP 47 5% 1/10W
R3134 1-216-805-11 METAL CHIP 47 5% 1/10W
R3203 1-218-969-11 METAL CHIP 22K 5% 1/16W
R3207 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3208 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3209 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3210 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3211 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3212 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3231 1-216-805-11 METAL CHIP 47 5% 1/10W
R3232 1-216-805-11 METAL CHIP 47 5% 1/10W
R3233 1-216-805-11 METAL CHIP 47 5% 1/10W
R3234 1-216-805-11 METAL CHIP 47 5% 1/10W
R3303 1-218-969-11 METAL CHIP 22K 5% 1/16W
R3307 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3308 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3309 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3310 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3311 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3312 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3331 1-216-805-11 METAL CHIP 47 5% 1/10W
R3332 1-216-805-11 METAL CHIP 47 5% 1/10W
R3333 1-216-805-11 METAL CHIP 47 5% 1/10W
R3334 1-216-805-11 METAL CHIP 47 5% 1/10W
R3551 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3552 1-218-989-11 METAL CHIP 1M 5% 1/16W
R3553 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3554 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3555 1-218-973-11 METAL CHIP 47K 5% 1/16W
R3556 1-218-969-11 METAL CHIP 22K 5% 1/16W
R3557 1-208-923-11 METAL CHIP 33K 0.5% 1/16W
R3558 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R3559 1-208-687-11 METAL CHIP 1.5K 0.5% 1/16W
R3560 1-218-977-11 METAL CHIP 100K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB3001 1-234-372-11 RES, NETWORK 100 (1005X4)
RB3002 1-234-372-11 RES, NETWORK 100 (1005X4)
< VIBRATOR >
X3051 1-814-418-11 QUARTZ CRYSTAL UNIT (49.152MHz)
************************************************************
A-1815-452-A DISPLAY BOARD, COMPLETE
(E280: US, CND, AUS, PX, MX/T28)
A-1815-453-A DISPLAY BOARD, COMPLETE (E280: AEP, IT, UK)
***********************
4-257-156-01 HOLDER, FL
< CAPACITOR >
C01 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C02 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C04 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C05 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C06 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C07 1-124-584-00 ELECT 100uF 20% 10V
C08 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C10 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C13 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C14 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C15 1-119-772-91 ELECT 47uF 20% 35V
C17 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C18 1-137-710-91 CERAMIC CHIP 10uF 20% 6.3V
C20 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C25 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C26 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C27 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C30 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C31 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C40 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C43 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN02 1-779-552-21 CONNECTOR, FFC (LIF (NON-ZIF)) 15P
< DIODE >
D02 6-501-579-01 DIODE MC2837
D03 6-501-579-01 DIODE MC2837
D05 6-503-014-01 DIODE DZ2J05100L
D06 6-502-961-01 DIODE DA2J10100L
< IC >
IC01 6-715-344-01 IC MM3404A50URE
AMP DISPLAY
Ver. 1.1
