Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-E280/T28
8383
IC02 6-701-729-01 IC PT6315
IC03 6-712-427-01 IC 74AHCT04PW-118
IC30 6-600-665-01 IC GP1UE27XK0VF
< COIL >
L01 1-421-967-21 INDUCTOR
100uH
L02 1-421-967-21 INDUCTOR 100uH
< FLUORESCENT INDICATOR TUBE >
ND01 1-483-324-11 VACUUM FLUORESCENT DISPLAY
(E280: AEP, IT, UK)
ND01 1-483-324-21 VACUUM FLUORESCENT DISPLAY
(E280: US, CND, AUS, PX, MX/T28)
< TRANSISTOR >
Q01 8-729-038-42 TRANSISTOR RT1N441M-TP-1
Q02 6-551-460-01 FET RSR025P03TL
Q03 6-552-713-01 TRANSISTOR QS5W2TR
Q04 6-552-408-01 TRANSISTOR DSC500100L
< RESISTOR >
R01 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R02 1-216-821-11 METAL CHIP 1K 5% 1/10W
R04 1-216-821-11 METAL CHIP 1K 5% 1/10W
R05 1-216-841-11 METAL CHIP 47K 5% 1/10W
R06 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R13 1-216-833-11 METAL CHIP 10K 5% 1/10W
R14 1-216-805-11 METAL CHIP 47 5% 1/10W
R17 1-216-805-11 METAL CHIP 47 5% 1/10W
R22 1-216-844-11 METAL CHIP 82K 5% 1/10W
R23 1-216-809-11 METAL CHIP 100 5% 1/10W
R24 1-216-809-11 METAL CHIP 100 5% 1/10W
R25 1-216-809-11 METAL CHIP 100 5% 1/10W
R26 1-216-853-11 METAL CHIP 470K 5% 1/10W
R27 1-216-845-11 METAL CHIP 100K 5% 1/10W
R28 1-216-295-91 SHORT CHIP 0
R29 1-216-813-11 METAL CHIP 220 5% 1/10W
R30 1-216-805-11 METAL CHIP 47 5% 1/10W
R31 1-216-813-11 METAL CHIP 220 5% 1/10W
R32 1-216-813-11 METAL CHIP 220 5% 1/10W
R40 1-216-809-11 METAL CHIP 100 5% 1/10W
R41 1-216-821-11 METAL CHIP 1K 5% 1/10W
R42 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R43 1-216-809-11 METAL CHIP 100 5% 1/10W
R44 1-216-821-11 METAL CHIP 1K 5% 1/10W
R45 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
< SWITCH >
S40 1-771-410-21 SWITCH, TACTILE (VOLUME +)
S41 1-771-410-21 SWITCH, TACTILE (N)
S42 1-771-410-21 SWITCH, TACTILE (Z)
S43 1-771-410-21 SWITCH, TACTILE (VOLUME –)
S44 1-771-410-21 SWITCH, TACTILE (FUNCTION)
S45 1-771-410-21 SWITCH, TACTILE (x)
< TRANSFORMER >
T01 1-445-935-11 DC-DC CONVERTER TRANSFORMER
************************************************************
FRONT USB BOARD
(E280: AEP, IT, UK, AUS, MX/T28: MX)
****************
< CONNECTOR >
CN601 1-564-721-11 PIN, CONNECTOR (SMALL TYPE) 5P
CN602 1-822-423-11 CONNECTOR, USB (A) (
)
************************************************************
9 A-1816-360-A MB-141 BOARD, COMPLETE (for SERVICE)
(E280: US)
9 A-1816-361-A MB-141 BOARD, COMPLETE (for SERVICE)
(E280: CND)
9 A-1816-362-A MB-141 BOARD, COMPLETE (for SERVICE)
(E280: PX)
9 A-1816-363-A MB-141 BOARD, COMPLETE (for SERVICE)
(E280: AEP)
9 A-1816-364-A MB-141 BOARD, COMPLETE (for SERVICE)
(E280: UK)
9 A-1816-366-A MB-141 BOARD, COMPLETE (for SERVICE)
(E280: AUS)
9 A-1816-367-A MB-141 BOARD, COMPLETE (for SERVICE)
(E280: MX)
9 A-1816-371-A MB-141 BOARD, COMPLETE (for SERVICE)
(T28: CND)
9 A-1816-372-A MB-141 BOARD, COMPLETE (for SERVICE)
(T28: MX)
9 A-1832-609-A MB-141 BOARD, COMPLETE (for SERVICE)
(E280: IT)
**********************
< CAPACITOR >
C100 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
C102 1-114-130-11 CERAMIC CHIP 1uF 10% 6.3V
C103 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C104 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C105 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C106 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C107 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C108 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C109 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C110 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C111 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C112 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C113 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C114 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C116 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C117 1-114-130-11 CERAMIC CHIP 1uF 10% 6.3V
C118 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C119 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C120 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C121 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C122 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C123 1-112-777-11 CERAMIC CHIP 0.01uF 10% 25V
C125 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C126 1-114-130-11 CERAMIC CHIP 1uF 10% 6.3V
C127 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C128 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
C129 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C131 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C133 1-112-777-11 CERAMIC CHIP 0.01uF 10% 25V
C134 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C135 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
MB-141DISPLAY FRONT USB
Ver. 1.1
