Sony HBD-E280 - MB-141 Board Disassembly

HBD-E280/T28
14
2-7. MB-141 BOARD
qf MB-141
board
8 wire (flat type)
(7 core) (CN5903)
5 wire (flat type)
(26 core) (CN5905)
6 connector (CN5302)
9 connector
(CN602)
4 connector
(CN5301)
7 fan connector (CN6501)
D
C
2 two screws
(BV3)
qs four screws
(BV3)
qs three screws
(BV3)
3 wire holder
qd
D
E
B
A
C
F
F
1 wire (flat type) (15 core) (CN6201)
E
A
B
qa three screws
(B3 u 5)
0 screw (BV3)
MB-141 board
AMP board
fan cable
:LUHVHWWLQJ
:LUHVHWWLQJ
MB-141 board wire holder
rear side
front side
0 two screws (BV3)
$(3,78.$86
MX)
Ver. 1.1
• Abbreviation
AUS : Australian model
IT : Italian model
MX : Mexican model
