Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-E280/T28
8181
C3217 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C3218 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3219 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3220 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C3221 1-112-246-11 ELECT 100uF 20% 35V
C3222 1-112-246-11 ELECT 100uF 20% 35V
C3223 1-131-704-11 FILM 1uF 5% 50V
C3224 1-131-704-11 FILM 1uF 5% 50V
C3225 1-112-831-31 ELECT 2200uF 20% 35V
C3226 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3227 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
C3228 1-114-869-11 CERAMIC CHIP 2.2uF 10% 6.3V
C3301 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C3302 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C3303 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C3304 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C3305 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C3306 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C3307 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C3308 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3309 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3310 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C3311 1-112-246-11 ELECT 100uF 20% 35V
C3312 1-112-246-11 ELECT 100uF 20% 35V
C3313 1-131-704-11 FILM 1uF 5% 50V
C3314 1-131-704-11 FILM 1uF 5% 50V
C3315 1-112-831-31 ELECT 2200uF 20% 35V
C3316 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3317 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C3318 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3319 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3320 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C3321 1-112-246-11 ELECT 100uF 20% 35V
C3322 1-112-246-11 ELECT 100uF 20% 35V
C3323 1-131-704-11 FILM 1uF 5% 50V
C3324 1-131-704-11 FILM 1uF 5% 50V
C3325 1-112-831-31 ELECT 2200uF 20% 35V
C3326 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3327 1-114-869-11 CERAMIC CHIP 2.2uF 10% 6.3V
C3328 1-114-869-11 CERAMIC CHIP 2.2uF 10% 6.3V
C3551 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C3552 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C3553 1-107-909-11 ELECT 47uF 20% 50V
C3554 1-112-777-11 CERAMIC CHIP 0.01uF 10% 25V
C3555 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C3911 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C3912 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3913 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C3914 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3915 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C3916 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3917 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C3918 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3921 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C3922 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3923 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C3924 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3925 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C3926 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3927 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C3928 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3941 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C3942 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3943 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C3944 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3945 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C3946 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3947 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C3948 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN3002 1-815-460-31 CONNECTOR, FFC/FPC 26P
< DIODE >
D3551 6-500-848-01 DIODE MC2840-T112-1
< IC >
IC3010 6-707-939-01 IC CXD9843AR
IC3020 6-707-939-01 IC CXD9843AR
IC3030 6-707-939-01
IC CXD9843AR
IC3050 6-714-743-01 IC MM3404A18URE
IC3051 6-706-492-01 IC TC7SHU04FU
IC3100 6-714-477-01 IC CXD9981TN
IC3200 6-714-477-01 IC CXD9981TN
IC3300 6-714-477-01 IC CXD9981TN
< COIL >
L3051 1-469-525-91 INDUCTOR 10uH
L3052 1-469-525-91 INDUCTOR 10uH
L3053 1-469-525-91 INDUCTOR 10uH
L3101 1-457-579-11 INDUCTOR 10uH
L3102 1-457-579-11 INDUCTOR 10uH
L3201 1-457-579-11 INDUCTOR 10uH
L3202 1-457-579-11 INDUCTOR 10uH
L3301 1-457-579-11 INDUCTOR 10uH
L3302 1-457-579-11 INDUCTOR 10uH
< TRANSISTOR >
Q3101 6-551-271-01 TRANSISTOR RT3AMMM
Q3102 6-551-271-01 TRANSISTOR RT3AMMM
Q3201 6-551-271-01 TRANSISTOR RT3AMMM
Q3202 6-551-271-01 TRANSISTOR RT3AMMM
Q3301 6-551-271-01 TRANSISTOR RT3AMMM
Q3302 6-551-271-01 TRANSISTOR RT3AMMM
Q3551 6-552-408-01 TRANSISTOR DSC500100L
Q3552 6-551-272-01 TRANSISTOR RT3CLLM
Q3553 6-552-408-01 TRANSISTOR DSC500100L
< RESISTOR >
R3011 1-218-949-11 METAL CHIP 470 5% 1/16W
R3012 1-218-949-11 METAL CHIP 470 5% 1/16W
R3013 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3014 1-216-801-11 METAL CHIP 22 5% 1/10W
R3015 1-216-805-11 METAL CHIP 47 5% 1/10W
R3017 1-216-805-11 METAL CHIP 47 5% 1/10W
R3021 1-218-949-11 METAL CHIP 470 5% 1/16W
R3022 1-218-949-11 METAL CHIP 470 5% 1/16W
R3023 1-216-801-11 METAL CHIP 22 5% 1/10W
R3024 1-216-805-11 METAL CHIP 47 5% 1/10W
R3027 1-216-805-11 METAL CHIP 47 5% 1/10W
AMP
Note: When the IC3100, IC3200 and IC3300 on the AMP board are replaced, spread the com-
pound referring to “NOTE OF REPLACING THE IC3100, IC3200 AND IC3300 ON THE
AMP BOARD AND THE COMPLETE AMP BOARD” on servicing notes (page 9).
