Pin No. Pin Name I/O Description
F18 AVDD33_CDAC_R - Power supply terminal (+3.3V)
F19 AVSS33_VDAC_X - Ground terminal
F21 VDIN34 O EEPROM input data selection signal output terminal
F22 VDIN23 I/O Not used
F24 EXTXER/DDC_SCL O I2C clock signal output to the HDMI input selector
F25 ETRXD0 I Receive data input terminal Not used
F26 ETCRS/HPG_RX O Hot plug detection signal output to the HDMI input selector
F27 VDINVSYNC O Vertical sync signal output terminal Not used
F28 VDINCLK O Video clock signal output terminal Not used
G1 INB I Main beam (B) input from the BD drive
G2 INA I Main beam (A) input from the BD drive
G3 TRINA I Tracking signal (A) input terminal Not used
G4 AUX1 I Monitoring signal input from the BD drive
G5 VWDC3O O Laser diode control voltage output terminal Not used
G6 AGND12_1A - Ground terminal
G7 AVSS12_REC - Ground terminal
G9 GPIO2 I/O Not used
G11 SPBCK/DIN2 I
SPDIF (for digital audio output) signal input from the digital in optical receiver or digital in
coaxial jack
G14 AVSS12_APLL - Ground terminal
G15 AVDD12_APLL - Power supply terminal (+1.2V)
G16 AVSS12_HDMI_TX - Ground terminal
G17 AVSS33_VDAC_R - Ground terminal
G20 VDIN35/LIN I/O Not used
G23 ETTXD0 O Transmit data output terminal Not used
G24 ETTXCLK O Transmit clock signal output terminal Not used
G25 ETRXD3 I Receive data input terminal Not used
G26 ETRXCLK I Receive clock signal input terminal Not used
G27,
G28
ETRXD1, ETRXD2 I Receive data input terminal Not used
H1 IND I Main beam (D) input from the BD drive
H2 INC I Main beam (C) input from the BD drive
H3 TRINC I Tracking signal (C) input terminal Not used
H4 TRINB I Tracking signal (B) input terminal Not used
H5 TRIND I Tracking signal (D) input terminal Not used
H6 FVREF O Reference voltage output terminal Not used
H21 DVCC33_IO_STB - Power supply terminal (+3.3V)
H22 AVSS33_LDO - Ground terminal
H23 ETTXD1 O Transmit data output terminal Not used
H24 GPIO8/5V_RX I Power supply voltage (+5V) input from the HDMI IN connector
H25 ETTXEN O Transmit enable signal output terminal Not used
H26 ETTXD3 O Transmit data output terminal Not used
J3 INH O Sub beam (H) input from the BD drive
J4 ING O Sub beam (G) input from the BD drive
J5 AVDD33_1A - Power supply terminal (+3.3V)
J6 AGND33_1A - Ground terminal
J13, J14 DVCC33_IO_5 - Power supply terminal (+3.3V)
J18, J19 DVCC33_IO_3 - Power supply terminal (+3.3V)
J21 DVCC33_IO_STB - Power supply terminal (+3.3V)
J23 ETTXD2 O Transmit data output terminal Not used
J24 AVDD33_LDO - Power supply terminal (+3.3V)
J25 UARXD I Receive data input terminal
J26 ETMDIO I/O Management data input/output terminal Not used
J27 ETCOL I Collision detection signal input terminal Not used
J28 ETMDC O Management data clock signal output terminal Not used
K1 RFIP I BD RF signal (positive) input from the BD drive
K2 RFIN I BD RF signal (negative) input from the BD drive
K3 INE O Sub beam (E) input from the BD drive
K4 INF O Sub beam (F) input from the BD drive
K5 HAVC O Reference voltage output to the BD drive
