18. Drive
This menu is used to operate the drive using drive-related diagnos-
tic and tools.
Screen 1: Selecting items under *Drive
Operation:
[
M
]/[
m
] Selects the category
[
m
]/[ ] Activate the selected category
[RETURN] Returns to the top menu of the service mode
[1] Drive OP data Write
[2] Servo Parameter Check Menu
[3] Servo Signal Check Menu
[4] S-Curve Check Menu
[5] Readability Check Menu
[6] OP Position Check Menu
[7] OP Check Menu
[8] Load Eject Aging
[9] Spindle Control Check Menu
[10] FA Test Mode
Screen 2: To start OP data Write
Operation:
[
] Starts
Screen 3: Show OP data Write result
Operation:
NG - USB is not fi nd
OK - OP data write
• Drive Test
For drive operating check. Service is only use Drive OP data write
to rewrite OP data after change of new CPU.

System Information
Sequence Number:
MAC:
IP:
Model:
Main LSIname:
Destination:
IF-con Block0 Version:
Bootloader Version:
Host Main Version:
MicroBE Version:
Host Sub Version:
Middleware Version:
ADSP Version:
ADSP Coeff Version:
HELP : [RET] [RIGHT]
(Screen 1)
 System Information
CD DIOP:
DVD DIOP:
WLAN module hw version:
WLAN module MAC Address:
Drive Firm Revision:
WLAN module Serial:
IF_MODEL:
IF_DEST:
BD DIOP:
CD LD TIME:
DVD LD TIME:
Bluetooth Device Address:
HELP : [RET] [LEFT]
(Screen 2)

Drive
[1] Drive OP data Write
 Drive OP data Write
Insert USB StorageDevice ...
Remove DISC and Close tray.
HELP: [ENT] [RET]
Disc : Load
Mode: 1
(Screen 1)
(Screen 2)
(Screen 3)
HELP: [ENT] [RET]

Drive OP data Write
Insert USB StorageDevice ...
Remove DISC and Close tray.
NG - USB is not find
OK - OP data write
[ENT] Start
[ENT] Start
