82
HBD-E2100/E3100/E3200/E4100/E6100
SECTION 8
ELECTRICAL PARTS LIST
0 A-1901-382-A AMP BOARD, COMPLETE (EXCEPT US)
0 A-1924-824-A AMP BOARD, COMPLETE (US)
********************
< CAPACITOR >
C3013 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C3014 1-118-668-11 CERAMIC CHIP 0.1uF 10% 50V
C3021 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C3022 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C3023 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C3025 1-118-668-11 CERAMIC CHIP 0.1uF 10% 50V
C3026 1-118-388-11 CERAMIC CHIP 0.047uF 10% 25V
C3027 1-118-689-81 CERAMIC CHIP 0.0047uF 5% 10V
C3028 1-118-388-11 CERAMIC CHIP 0.047uF 10% 25V
C3029 1-118-689-81 CERAMIC CHIP 0.0047uF 5% 10V
C3031 1-118-668-11 CERAMIC CHIP 0.1uF 10% 50V
C3032 1-118-668-11 CERAMIC CHIP 0.1uF 10% 50V
C3033 1-118-668-11 CERAMIC CHIP 0.1uF 10% 50V
C3041 1-118-668-11 CERAMIC CHIP 0.1uF 10% 50V
C3042 1-118-668-11 CERAMIC CHIP 0.1uF 10% 50V
C3050 1-165-979-21 ELECT CHIP 100uF 20% 6.3V
C3051 1-164-232-91 CERAMIC CHIP 0.01uF 10% 100V
C3099 1-118-691-11 CERAMIC CHIP 2.2uF 10% 100V
C3106 1-118-698-11 CERAMIC CHIP 0.1uF 10% 100V
C3107 1-118-698-11 CERAMIC CHIP 0.1uF 10% 100V
C3108 1-118-691-11 CERAMIC CHIP 2.2uF 10% 100V
C3109 1-118-691-11 CERAMIC CHIP 2.2uF 10% 100V
C3115 1-118-668-11 CERAMIC CHIP 0.1uF 10% 50V
C3117 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3118 1-118-691-11 CERAMIC CHIP 2.2uF 10% 100V
C3119 1-118-691-11 CERAMIC CHIP 2.2uF 10% 100V
C3120 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3122 1-118-668-11 CERAMIC CHIP 0.1uF 10% 50V
C3123 1-114-920-21 CERAMIC CHIP 0.47uF 10% 250V
C3124 1-114-920-21 CERAMIC CHIP 0.47uF 10% 250V
C3127 1-116-731-11 CERAMIC CHIP 2.2uF 20% 6.3V
C3131 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C3133 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C3134 1-118-698-11 CERAMIC CHIP 0.1uF 10% 100V
C3135 1-118-698-11 CERAMIC CHIP 0.1uF 10% 100V
C3136 1-118-668-11 CERAMIC CHIP 0.1uF 10% 50V
C3138 1-118-668-11 CERAMIC CHIP 0.1uF 10% 50V
C3139 1-118-668-11 CERAMIC CHIP 0.1uF 10% 50V
C3140 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3141 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3151 1-118-470-31 ELECT 560uF 20% 35V
C3152 1-118-470-31 ELECT 560uF 20% 35V
C3153 1-118-470-31 ELECT 560uF 20% 35V
C3154 1-118-470-31 ELECT 560uF 20% 35V
C3156 1-118-698-11 CERAMIC CHIP 0.1uF 10% 100V
C3157 1-118-698-11 CERAMIC CHIP 0.1uF 10% 100V
* C3228 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C3251 1-118-122-11 ELECT 270uF 20% 63V (US)
C3251 1-118-453-31 ELECT 270uF 20% 63V
(EXCEPT US)
C3253 1-118-122-11 ELECT 270uF 20% 63V (US)
C3253 1-118-453-31 ELECT 270uF 20% 63V
(EXCEPT US)
C3271 1-100-154-91 CERAMIC CHIP 330PF 5% 100V
C3272 1-100-154-91 CERAMIC CHIP 330PF 5% 100V
C3281 1-100-154-91 CERAMIC CHIP 330PF 5% 100V
C3282 1-100-154-91 CERAMIC CHIP 330PF 5% 100V
C3306 1-118-698-11 CERAMIC CHIP 0.1uF 10% 100V
C3307 1-118-698-11 CERAMIC CHIP 0.1uF 10% 100V
C3308 1-118-691-11 CERAMIC CHIP 2.2uF 10% 100V
C3309 1-118-691-11 CERAMIC CHIP 2.2uF 10% 100V
C3315 1-118-668-11 CERAMIC CHIP 0.1uF 10% 50V
C3317 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3318 1-118-691-11 CERAMIC CHIP 2.2uF 10% 100V
C3319 1-118-691-11 CERAMIC CHIP 2.2uF 10% 100V
C3320 1-118-668-11 CERAMIC CHIP 0.1uF 10% 50V
C3322 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3323 1-114-920-21 CERAMIC CHIP 0.47uF 10% 250V
C3324 1-114-920-21 CERAMIC CHIP 0.47uF 10% 250V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AMP
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
AR : Argentina model
AUS : Australian model
CH : Chinese model
CND : Canadian model
E3 : 240 V AC area in E model
E12 : 220 – 240 V AC area in E model
E32 : 110 – 240 V AC area in E model
E51 : Chilean and Peruvian models
EA : Saudi Arabia model
MX6 : Latin-American model
PX : PX model
RU : Russian model
SAF : South African model
SP : Singapore model
TH : Thai model
TW : Taiwan model
When indicating parts by reference num-
ber, please include the board name.
Note: When the AMP board is replaced, spread the compound referring to “NOTE OF
REPLACING THE IC3102 AND IC3302 ON THE AMP BOARD AND THE
COMPLETE AMP BOARD” on servicing notes (page 10).
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce por-
tant le numéro spécifi é.
The components identifi ed by mark 9 con-
tain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Les composants identifi és par la marque
9 contiennent des informations confi den-
tielles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est remplacé
et / ou réparé.
Ver. 1.7
