Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-E2100/E3100/E3200/E4100/E6100
83
C3328 1-116-731-11 CERAMIC CHIP 2.2uF 20% 6.3V
C3331 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C3333 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C3334 1-118-698-11 CERAMIC CHIP 0.1uF 10% 100V
C3335 1-118-698-11 CERAMIC CHIP 0.1uF 10% 100V
C3336 1-118-668-11 CERAMIC CHIP 0.1uF 10% 50V
C3338 1-118-668-11 CERAMIC CHIP 0.1uF 10% 50V
C3339 1-118-668-11 CERAMIC CHIP 0.1uF 10% 50V
C3340 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3341 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3351 1-118-470-31 ELECT 560uF 20% 35V
C3352 1-118-470-31 ELECT 560uF 20% 35V
C3353 1-118-470-31 ELECT 560uF 20% 35V
C3354 1-118-470-31 ELECT 560uF 20% 35V
C3356 1-118-698-11 CERAMIC CHIP 0.1uF 10% 100V
C3357 1-118-698-11 CERAMIC CHIP 0.1uF 10% 100V
C3371 1-100-154-91 CERAMIC CHIP 330PF 5% 100V
C3372 1-100-154-91 CERAMIC CHIP 330PF 5% 100V
C3381 1-100-154-91 CERAMIC CHIP 330PF 5% 100V
C3382 1-100-154-91 CERAMIC CHIP 330PF 5% 100V
C3401 1-164-232-91 CERAMIC CHIP 0.01uF 10% 100V
C3402 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3403 1-164-232-91 CERAMIC CHIP 0.01uF 10% 100V
C3404 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3405 1-164-232-91 CERAMIC CHIP 0.01uF 10% 100V
C3406 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3407 1-164-232-91 CERAMIC CHIP 0.01uF 10% 100V
C3408 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3451 1-164-232-91 CERAMIC CHIP 0.01uF 10% 100V
C3452 1-164-232-91 CERAMIC CHIP 0.01uF 10% 100V
C3453 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3454 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3455 1-164-232-91 CERAMIC CHIP 0.01uF 10% 100V
C3456 1-164-232-91 CERAMIC CHIP 0.01uF 10% 100V
C3457 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3458 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3459 1-164-232-91 CERAMIC CHIP 0.01uF 10% 100V
C3460 1-164-232-91 CERAMIC CHIP 0.01uF 10% 100V
C3461 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3462 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3463 1-164-232-91 CERAMIC CHIP 0.01uF 10% 100V
C3464 1-164-232-91 CERAMIC CHIP 0.01uF 10% 100V
C3465 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3466 1-100-158-91 CERAMIC CHIP 1000PF 5% 100V
C3552 1-126-208-21 ELECT CHIP 47uF 20% 4V
C3554 1-116-405-11 CERAMIC CHIP 0.01uF 10% 100V
C3555 1-118-668-11 CERAMIC CHIP 0.1uF 10% 50V
C3557 1-112-777-11 CERAMIC CHIP 0.01uF 10% 25V
C3570 1-100-908-11 CERAMIC CHIP 1uF 10% 6.3V
C3949 1-114-920-21 CERAMIC CHIP 0.47uF 10% 250V
C3950 1-114-920-21 CERAMIC CHIP 0.47uF 10% 250V
C3951 1-114-920-21 CERAMIC CHIP 0.47uF 10% 250V
C3952 1-114-920-21 CERAMIC CHIP 0.47uF 10% 250V
< CONNECTOR >
CN3505 1-815-763-32 CONNECTOR, FFC/FPC 24P
< DIODE >
D3101 6-503-967-01 DI STPS1H100A
D3102 6-503-967-01 DI STPS1H100A
D3103 6-503-967-01 DI STPS1H100A
D3104 6-503-967-01 DI STPS1H100A
D3105 6-503-967-01 DI STPS1H100A
D3106 6-503-967-01 DI STPS1H100A
D3107 6-503-967-01 DI STPS1H100A
D3108 6-503-967-01 DI STPS1H100A
D3151 6-503-761-01 DI RB751S40, 115
D3301 6-503-967-01 DI STPS1H100A
D3302 6-503-967-01 DI STPS1H100A
D3303 6-503-967-01 DI STPS1H100A
D3304 6-503-967-01 DI STPS1H100A
D3305 6-503-967-01 DI STPS1H100A
D3306 6-503-967-01 DI STPS1H100A
D3307 6-503-967-01 DI STPS1H100A
D3308 6-503-967-01 DI STPS1H100A
D3351 6-503-761-01 DI RB751S40, 115
D3503 6-503-761-01 DI RB751S40, 115
< IC >
IC3001 6-718-103-01 IC TAS5538DGGR
IC3102 6-719-138-01 IC STA516BF13TR-A
IC3302 6-719-138-01 IC STA516BF13TR-A
< COIL >
L3051 1-400-791-21 INDUCTOR 10uH
L3101 1-482-176-11 INDUCTOR 20uH
L3103 1-482-176-11 INDUCTOR 20uH
L3301 1-482-176-11 INDUCTOR 20uH
L3303 1-482-176-11 INDUCTOR 20uH
< TRANSISTOR >
Q3101 8-729-013-22 TR HN1A01FU
Q3202 8-729-013-22 TR HN1A01FU
Q3302 8-729-013-22 TR HN1A01FU
Q3552 8-729-427-72 TRANSISTOR XP4501
Q3553 6-552-892-01 TR LSCR523UBFS8TL
Q3555 8-729-013-22 TR HN1A01FU
< RESISTOR >
R3021 1-218-968-11 METAL CHIP 18K 5% 1/16W
R3022 1-218-967-11 METAL CHIP 15K 5% 1/16W
R3023 1-218-949-11 METAL CHIP 470 5% 1/16W
R3024 1-218-949-11 METAL CHIP 470 5% 1/16W
R3032 1-216-295-91 SHORT CHIP 0
R3033 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3041 1-218-937-11 METAL CHIP 47 5% 1/16W
R3051 1-216-845-11 METAL CHIP 100K 5% 1/10W
R3059 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3060 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3061 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3062 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3072 1-218-937-11 METAL CHIP 47 5% 1/16W
R3073 1-218-937-11 METAL CHIP 47 5% 1/16W
R3109 1-218-977-11 METAL CHIP 100K 5% 1/16W
R3153 1-220-281-11 METAL CHIP 4.7K 5% 1/4W
R3154 1-220-281-11 METAL CHIP 4.7K 5% 1/4W
R3155 1-220-281-11 METAL CHIP 4.7K 5% 1/4W
R3156 1-220-281-11 METAL CHIP 4.7K 5% 1/4W
R3161 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3162 1-218-965-11 METAL CHIP 10K 5% 1/16W
AMP
Note: When the IC3102 and IC3302 on the AMP board are replaced, spread the
compound referring to “NOTE OF REPLACING THE IC3102 and IC3302 ON THE
AMP BOARD AND THE COMPLETE AMP BOARD” on servicing notes (page 10).
