Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
90
HCD-AZ2D/AZ5D
R3784 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R3785 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3786 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3787 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3788 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R3789 1-216-821-11 METAL CHIP 1K 5% 1/10W
R3801 1-216-864-11 SHORT CHIP 0
R3802 1-216-864-11 SHORT CHIP 0
R3803 1-216-833-11 METAL CHIP 10K 5% 1/10W
R3804 1-216-836-11 METAL CHIP 18K 5% 1/10W
R3805 1-216-821-11 METAL CHIP 1K 5% 1/10W
R4701 1-216-864-11 SHORT CHIP 0
R4702 1-216-864-11 SHORT CHIP 0
R4703 1-216-864-11 SHORT CHIP 0
R4704 1-216-864-11 SHORT CHIP 0
R4705 1-216-864-11 SHORT CHIP 0
R4706 1-216-864-11 SHORT CHIP 0
R5008 1-216-864-11 SHORT CHIP 0 (AZ2D)
R5009 1-216-864-11 SHORT CHIP 0 (AZ5D)
R5010 1-216-864-11 SHORT CHIP 0
R5014 1-216-864-11 SHORT CHIP 0 (AZ2D: E2/AZ5D: E2)
R5016 1-216-864-11 SHORT CHIP 0
(AZ2D: E3, E12, E13, E15, EA, AUS/AZ5D: E3, E12, E15, EA, AUS)
R5017 1-216-864-11 SHORT CHIP 0
(AZ2D: SP, MY, KR, PH/AZ5D: SP, MY, TH)
< COMPOSITION CIRCUIT BLOCK >
RB103 1-234-795-21 RES, NETWORK 0X4 (2010)
RB104 1-234-795-21 RES, NETWORK 0X4 (2010)
RB105 1-234-371-21 RES, NETWORK 47 (1005X4)
RB106 1-234-371-21 RES, NETWORK 47 (1005X4)
RB107 1-234-370-21 RES, NETWORK 22 (1005X4)
RB108 1-234-370-21 RES, NETWORK 22 (1005X4) 22 (1005X4)
RB111 1-234-795-21 RES, NETWORK 0X4 (2010)
RB112 1-234-370-21 RES, NETWORK 22 (1005X4) 22 (1005X4)
RB113 1-234-370-21 RES, NETWORK 22 (1005X4) 22 (1005X4)
< VIBRATOR >
X101 1-781-867-21 VIBRATOR, CRYSTAL (27MHz)
*************************************************************
EJECT BOARD
***********
< RESISTOR >
R1039 1-216-833-11 METAL CHIP 10K 5% 1/10W
< SWITCH >
S1041 1-762-875-21 SWITCH, KEYBOARD (Z)
*************************************************************
A-1091-269-A FL BOARD, COMPLETE (EXCEPT AZ5D: TH)
A-1114-866-A FL BOARD, COMPLETE (AZ5D: TH)
********
< CAPACITOR >
C1001 1-126-514-11 ELECT 22uF 20% 16V
C1002 1-107-727-61 CERAMIC CHIP 0.022uF 10% 16V
C1003 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1004 1-119-943-11 ELECT 47uF 20% 50V
C1005 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1006 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C1007 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1008 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1009 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1010 1-162-922-11 CERAMIC CHIP 39PF 5% 50V
C1011 1-126-964-11 ELECT 10uF 20% 50V
C1012 1-126-964-11 ELECT 10uF 20% 50V
C1013 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C1014 1-162-974-11 CERAMIC CHIP 0.01uF 50V
< CONNECTOR >
CN1001 1-784-735-11 CONNECTOR, FFC 13P
< DIODE >
D1001 8-719-988-61 DIODE 1SS355TE-17
D1002 8-719-988-61 DIODE 1SS355TE-17
D1003 8-719-988-61 DIODE 1SS355TE-17
D1004 8-719-988-61 DIODE 1SS355TE-17
D1005 8-719-083-58 DIODE UDZSTE-173.9B
D1006 6-500-809-01 LED SELU5223C-STP15 (BACK LIGHT)
D1007 6-500-809-01 LED SELU5223C-STP15 (BACK LIGHT)
D1008 6-500-809-01 LED SELU5223C-STP15 (BACK LIGHT)
D1009 6-500-809-01 LED SELU5223C-STP15 (BACK LIGHT)
D1010 6-500-809-01 LED SELU5223C-STP15 (BACK LIGHT)
< FLUORESCENT INDICATOR >
FL1001 1-519-789-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC1001 6-705-899-01 IC ML9208-03MBZ03B
< COIL >
L1001 1-410-671-31 INDUCTOR 47uH
< TRANSISTOR >
Q1001 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q1002 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q1003 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1004 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q1005 6-550-065-01 TRANSISTOR CPH5504-TL-E
< RESISTOR >
R1001 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1002 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1003 1-216-809-11 METAL CHIP 100 5% 1/10W
R1004 1-216-809-11 METAL CHIP 100 5% 1/10W
R1006 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1007 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1008 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1009 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1010 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1011 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1012 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1013 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
DMB10 EJECT FL
