Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
91
HCD-AZ2D/AZ5D
R1014 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1015 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1016 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1017 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1018 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1019 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1020 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1021 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1022 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1023 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1024 1-216-833-11 METAL CHIP 10K 5% 1/10W
< TRANSFORMER >
T1001 1-443-576-11 TRANSFORMER, DC/DC CONVERTER
*************************************************************
KEY BOARD
*********
< CONNECTOR >
CN1030 1-784-727-11 CONNECTOR, FFC 5P
< LED >
D1030 8-719-071-44 LED SELS5223C-TP15 (STANDBY)
< RESISTOR >
R1030 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1031 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1032 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1033 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1034 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1035 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1036 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1037 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1038 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
< SWITCH >
S1030 1-762-875-21 SWITCH, KEYBOARD (?/1)
S1031 1-762-875-21 SWITCH, KEYBOARD (DIMMER)
S1032 1-762-875-21 SWITCH, KEYBOARD (PROGRESSIVE)
S1033 1-762-875-21 SWITCH, KEYBOARD (DSGX)
S1034 1-762-875-21 SWITCH, KEYBOARD (SOUND FILED)
S1035 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S1036 1-762-875-21 SWITCH, KEYBOARD (EQ SELECT)
S1037 1-762-875-21 SWITCH, KEYBOARD (DIRECTION)
S1038 1-762-875-21 SWITCH, KEYBOARD (CD SYNC)
S1039 1-762-875-21 SWITCH, KEYBOARD (z START)
*************************************************************
A-1091-182-A MAIN BOARD, COMPLETE (AZ2D: SP, MY)
A-1091-183-A MAIN BOARD, COMPLETE (AZ2D: E2)
A-1091-184-A MAIN BOARD, COMPLETE (AZ2D: E13)
A-1091-185-A MAIN BOARD, COMPLETE (AZ5D: SP, MY)
A-1091-186-A MAIN BOARD, COMPLETE (AZ5D: E2)
A-1092-100-A MAIN BOARD, COMPLETE (AZ2D: AUS)
A-1092-101-A MAIN BOARD, COMPLETE (AZ2D: EA)
A-1092-102-A MAIN BOARD, COMPLETE (AZ2D: KR)
A-1092-103-A MAIN BOARD, COMPLETE (AZ5D: AUS)
A-1092-104-A MAIN BOARD, COMPLETE (AZ5D: EA)
A-1114-671-A MAIN BOARD, COMPLETE (AZ2D: PH)
A-1114-680-A MAIN BOARD, COMPLETE (AZ2D: E15)
A-1114-696-A MAIN BOARD, COMPLETE (AZ2D: E3)
A-1114-703-A MAIN BOARD, COMPLETE (AZ2D: E12)
A-1114-711-A MAIN BOARD, COMPLETE (AZ5D: E15)
A-1114-719-A MAIN BOARD, COMPLETE (AZ5D: E3)
A-1114-745-A MAIN BOARD, COMPLETE (AZ5D: E12)
A-1114-860-A MAIN BOARD, COMPLETE (AZ5D: TH)
**********
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C1 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C2 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C3 1-115-156-11 CERAMIC CHIP 1uF 10V
C4 1-126-964-11 ELECT 10uF 20% 50V
C10 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C11 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C12 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C13 1-115-156-11 CERAMIC CHIP 1uF 10V
C14 1-126-947-11 ELECT 47uF 20% 35V
C15 1-126-947-11 ELECT 47uF 20% 35V
C16 1-115-156-11 CERAMIC CHIP 1uF 10V
C17 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C18 1-115-156-11 CERAMIC CHIP 1uF 10V
C19 1-126-963-11 ELECT 4.7uF 20% 50V
C20 1-126-963-11 ELECT 4.7uF 20% 50V
C29 1-126-964-11 ELECT 10uF 20% 50V
C30 1-126-964-11 ELECT 10uF 20% 50V
C31 1-124-261-00 ELECT 10uF 20% 50V
C32 1-124-261-00 ELECT 10uF 20% 50V
C33 1-126-964-11 ELECT 10uF 20% 50V
(AZ5D)
C34 1-126-964-11 ELECT 10uF 20% 50V
(AZ5D)
C35 1-126-964-11 ELECT 10uF 20% 50V
(AZ5D)
C36 1-126-964-11 ELECT 10uF 20% 50V
(AZ5D)
C51 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C52 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C53 1-115-156-11 CERAMIC CHIP 1uF 10V
C54 1-126-964-11 ELECT 10uF 20% 50V
C70 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C72 1-126-964-11 ELECT 10uF 20% 50V
C73 1-126-963-11 ELECT 4.7uF 20% 50V
C74 1-126-963-11 ELECT 4.7uF 20% 50V
C75 1-126-964-11 ELECT 10uF 20% 50V
C77 1-126-935-11 ELECT 470uF 20% 16V
C79 1-126-964-11 ELECT 10uF 20% 50V
C82 1-126-964-11 ELECT 10uF 20% 50V
C85 1-126-964-11 ELECT 10uF 20% 50V
C87 1-126-935-11 ELECT 470uF 20% 16V
C89 1-126-964-11 ELECT 10uF 20% 50V
C90 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C93 1-126-926-11 ELECT 1000uF 20% 10V
C94 1-126-964-11 ELECT 10uF 20% 50V
