(5) BASE UNIT SECTION
(BU-K5BD41)
201
201
201
201
202
202
202
202
203
204
205
206
206
206
206
207
208
#7
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
201 4-985-672-01 SCREW (+PTPWHM2.6), FLOATING
202 4-229-005-01 INSULATOR
0203 8-848-483-05 OPTICAL PICK-UP KSM-213CKP/K1N
204 A-4725-097-A CD BOARD, COMPLETE
205 1-791-495-11 WIRE, PARALLEL (FFC) (16 CORE)
206 4-229-004-01 SPRING, COMPRESSION
207 4-227-251-01 HOLDER (KSM)
208 4-221-817-02 SHAFT (BU)
