Sony HCD-CP2A - Page 41

41
(4) CD MECHANISM DECK SECTION
(CDM55D-K5BD41)
153
152
157
154
155
156
160
158
151
159
166
165
162
163
161
164
M901
#6
BU-K5BD41
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
151 4-224-894-01 TRAY
152 4-220-229-01 LEVER (SW)
153 4-220-239-01 SPRING, TORSION
154 4-221-816-01 BELT (CDM55)
155 4-220-234-01 PULLEY (LDG)
156 4-220-237-01 GEAR (A)
157 4-220-238-01 GEAR (B)
158 4-220-233-01 CAM (CDM55)
159 1-676-599-11 LOADING BOARD
160 4-221-815-01 ROLLER
161 4-225-884-01 CHASSIS (55D)
162 X-4952-811-1 PULLEY (AT) ASSY
163 4-220-951-02 SHEET (KH)
164 4-985-672-01 SCREW (+PTPWHM2.6), FLOATING
165 4-925-315-31 DAMPER
166 4-227-598-01 SPACER (55)
M901 A-4672-891-A MOTOR (LD) ASSY (LOADING)
