Sony HCD-CP2A - Page 51

51
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R634 1-216-013-00 METAL CHIP 33 5% 1/10W
R639 1-216-049-11 RES-CHIP 1K 5% 1/10W
R640 1-216-049-11 RES-CHIP 1K 5% 1/10W
R641 1-216-049-11 RES-CHIP 1K 5% 1/10W
R642 1-216-049-11 RES-CHIP 1K 5% 1/10W
R643 1-216-049-11 RES-CHIP 1K 5% 1/10W
R644 1-216-049-11 RES-CHIP 1K 5% 1/10W
R645 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R646 1-216-049-11 RES-CHIP 1K 5% 1/10W
R647 1-216-049-11 RES-CHIP 1K 5% 1/10W
R648 1-216-049-11 RES-CHIP 1K 5% 1/10W
R649 1-216-049-11 RES-CHIP 1K 5% 1/10W
R650 1-216-049-11 RES-CHIP 1K 5% 1/10W
R651 1-216-049-11 RES-CHIP 1K 5% 1/10W
R652 1-216-049-11 RES-CHIP 1K 5% 1/10W
R653 1-216-025-00 RES-CHIP 100 5% 1/10W
R654 1-216-049-11 RES-CHIP 1K 5% 1/10W
R655 1-216-049-11 RES-CHIP 1K 5% 1/10W
R656 1-216-049-11 RES-CHIP 1K 5% 1/10W
R657 1-216-049-11 RES-CHIP 1K 5% 1/10W
R658 1-216-049-11 RES-CHIP 1K 5% 1/10W
R659 1-216-049-11 RES-CHIP 1K 5% 1/10W
R660 1-216-049-11 RES-CHIP 1K 5% 1/10W
R661 1-216-049-11 RES-CHIP 1K 5% 1/10W
R662 1-216-049-11 RES-CHIP 1K 5% 1/10W
R664 1-216-049-11 RES-CHIP 1K 5% 1/10W
R665 1-216-049-11 RES-CHIP 1K 5% 1/10W
R666 1-216-049-11 RES-CHIP 1K 5% 1/10W
R667 1-216-049-11 RES-CHIP 1K 5% 1/10W
R668 1-216-049-11 RES-CHIP 1K 5% 1/10W
R669 1-216-049-11 RES-CHIP 1K 5% 1/10W
R670 1-216-049-11 RES-CHIP 1K 5% 1/10W
R671 1-216-049-11 RES-CHIP 1K 5% 1/10W
R674 1-216-049-11 RES-CHIP 1K 5% 1/10W
R675 1-216-049-11 RES-CHIP 1K 5% 1/10W
R676 1-216-049-11 RES-CHIP 1K 5% 1/10W
R677 1-216-049-11 RES-CHIP 1K 5% 1/10W
R678 1-216-049-11 RES-CHIP 1K 5% 1/10W
R679 1-216-049-11 RES-CHIP 1K 5% 1/10W
R680 1-216-049-11 RES-CHIP 1K 5% 1/10W
R681 1-249-403-11 CARBON 68 5% 1/4W
R682 1-216-027-00 METAL CHIP 120 5% 1/10W
R683 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R684 1-216-037-00 METAL CHIP 330 5% 1/10W
R685 1-216-031-00 METAL CHIP 180 5% 1/10W
R686 1-216-031-00 METAL CHIP 180 5% 1/10W
R687 1-216-089-00 RES-CHIP 47K 5% 1/10W
R688 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R693 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R694 1-216-045-00 METAL CHIP 680 5% 1/10W
(AUS)
R694 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
(EA)
R694 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
(AEP, UK)
R695 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R696 1-216-097-00 RES-CHIP 100K 5% 1/10W
R697 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R853 1-216-113-00 METAL CHIP 470K 5% 1/10W
(AEP, UK)
R854 1-216-049-11 RES-CHIP 1K 5% 1/10W
(AEP, UK)
R855 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
(AEP, UK)
R856 1-216-097-00 RES-CHIP 100K 5% 1/10W
(AEP, UK)
R857 1-216-035-00 METAL CHIP 270 5% 1/10W
(AEP, UK)
R860 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R861 1-216-089-00 RES-CHIP 47K 5% 1/10W
R862 1-216-065-00 RES-CHIP 4.7K 5% 1/10W
R863 1-216-089-00 RES-CHIP 47K 5% 1/10W
R870 1-216-073-00 METAL CHIP 10K 5% 1/10W
R888 1-216-073-00 METAL CHIP 10K 5% 1/10W
R891 1-216-089-00 RES-CHIP 47K 5% 1/10W
R892 1-216-041-00 METAL CHIP 470 5% 1/10W
R898 1-216-242-00 RES-CHIP 68K 5% 1/8W
(AEP, UK)
R899 1-216-242-00 RES-CHIP 68K 5% 1/8W
(AEP, UK)
< VARIABLE RESISTOR >
RV101 1-241-764-11 RES, ADJ, CARBON 10K
RV201 1-241-764-11 RES, ADJ, CARBON 10K
< VIBRATOR >
X800 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
X801 1-767-184-11 VIBRATOR, CERAMIC (4.19MHz)
X802 1-579-242-41 VIBRATOR, CRYSTAL (4.332MHz) (AEP, UK)
**************************************************************
1-678-416-11 POWER BOARD
*************
1-533-313-11 HOLDER, FUSE
< CAPACITOR >
0C901 1-113-925-11 CERAMIC 0.01uF 20% 250V
(AEP, UK, AUS)
C907 1-101-005-00 CERAMIC 22000PF 50V
C908 1-101-005-00 CERAMIC 22000PF 50V
C909 1-101-005-00 CERAMIC 22000PF 50V
C910 1-101-005-00 CERAMIC 22000PF 50V
C911 1-161-494-00 CERAMIC 0.022uF 25V
C912 1-161-494-00 CERAMIC 0.022uF 25V
C913 1-161-494-00 CERAMIC 0.022uF 25V
C914 1-161-494-00 CERAMIC 0.022uF 25V
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR 2P
CN902 1-766-276-11 PIN, CONNECTOR (PC BOARD) 3P
CN903 1-766-278-11 PIN, CONNECTOR (PC BOARD) 5P
< DIODE >
D901 8-719-200-82 DIODE 11ES2 (AEP, UK, AUS)
D907 8-719-902-17 DIODE U15G
D908 8-719-902-17 DIODE U15G
D909 8-719-902-17 DIODE U15G
MAIN POWER
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
