52
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
D910 8-719-902-17 DIODE U15G
D911 8-719-046-07 DIODE 2A02M
D912 8-719-046-07 DIODE 2A02M
D913 8-719-046-07 DIODE 2A02M
D914 8-719-046-07 DIODE 2A02M
< FUSE >
0F901 1-533-464-11 FUSE, TIME-LAG (DIA. 5) (T0.8AL/250V)
0F902 1-533-468-11 FUSE, TIME-LAG (DIA. 5) (T2AL/250V)
0F903 1-533-468-11 FUSE, TIME-LAG (DIA. 5) (T2AL/250V)
< RELAY >
0RY901 1-755-386-11 RELAY (AEP, UK, AUS)
< SWITCH >
0S901 1-552-921-00 SWITCH, POWER (VOLTAGE SELECTOR) (EA)
< POWER TRANSFORMER >
0T901 1-435-386-11 TRANSFORMER, POWER (AEP, UK, AUS)
0T901 1-435-628-11 TRANSFORMER, POWER (EA)
**************************************************************
A-4473-593-A TC BOARD, COMPLETE
*******************
< CAPACITOR >
C401 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C402 1-104-665-11 ELECT 100uF 20% 16V
C403 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C404 1-130-487-00 MYLAR 0.022uF 5% 50V
C405 1-126-965-11 ELECT 22uF 20% 50V
C406 1-163-007-11 CERAMIC CHIP 680PF 10% 50V
C407 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C408 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C409 1-104-665-11 ELECT 100uF 20% 16V
C411 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C412 1-104-665-11 ELECT 100uF 20% 16V
C413 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C414 1-130-487-00 MYLAR 0.022uF 5% 50V
C415 1-126-965-11 ELECT 22uF 20% 50V
C421 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C422 1-104-665-11 ELECT 100uF 20% 16V
C423 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C424 1-130-487-00 MYLAR 0.022uF 5% 50V
C425 1-126-965-11 ELECT 22uF 20% 50V
C426 1-163-007-11 CERAMIC CHIP 680PF 10% 50V
C427 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C428 1-163-263-11 CERAMIC CHIP 330PF 5% 50V
C431 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C432 1-104-665-11 ELECT 100uF 20% 16V
C433 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C434 1-130-487-00 MYLAR 0.022uF 5% 50V
C435 1-126-965-11 ELECT 22uF 20% 50V
C461 1-104-665-11 ELECT 100uF 20% 16V
C462 1-104-665-11 ELECT 100uF 20% 16V
C463 1-104-665-11 ELECT 100uF 20% 16V
C464 1-104-665-11 ELECT 100uF 20% 16V
C466 1-126-964-11 ELECT 10uF 20% 50V
C467 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C468 1-137-150-11 MYLAR 0.01uF 5% 100V
C470 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
C471 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
C472 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C473 1-126-964-11 ELECT 10uF 20% 50V
C480 1-130-485-00 MYLAR 0.015uF 5% 50V
< CONNECTOR >
CN401 1-569-931-11 CONNECTOR, FFC/FPC 14P
< IC >
IC401 8-759-261-93 IC NJM4580LD
IC402 8-759-261-93 IC NJM4580LD
IC403 8-759-508-69 IC BA3126N
< COIL >
L401 1-469-449-11 INDUCTOR 100uH
< TRANSISTOR >
Q401 8-729-036-89 TRANSISTOR KTC3198GR-A
Q402 8-729-036-89 TRANSISTOR KTC3198GR-A
Q403 8-729-036-89 TRANSISTOR KTC3198GR-A
Q404 8-729-037-02 TRANSISTOR KTA1266Y-AT
< RESISTOR >
R401 1-216-107-00 METAL CHIP 270K 5% 1/10W
R402 1-216-025-00 RES-CHIP 100 5% 1/10W
R403 1-216-068-00 METAL CHIP 6.2K 5% 1/10W
R404 1-216-101-00 METAL CHIP 150K 5% 1/10W
R405 1-216-025-00 RES-CHIP 100 5% 1/10W
R406 1-216-075-00 METAL CHIP 12K 5% 1/10W
R411 1-216-107-00 METAL CHIP 270K 5% 1/10W
R412 1-216-025-00 RES-CHIP 100 5% 1/10W
R413 1-216-068-00 METAL CHIP 6.2K 5% 1/10W
R414 1-216-101-00 METAL CHIP 150K 5% 1/10W
R421 1-216-107-00 METAL CHIP 270K 5% 1/10W
R422 1-216-025-00 RES-CHIP 100 5% 1/10W
R423 1-216-068-00 METAL CHIP 6.2K 5% 1/10W
R424 1-216-101-00 METAL CHIP 150K 5% 1/10W
R425 1-216-025-00 RES-CHIP 100 5% 1/10W
R426 1-216-075-00 METAL CHIP 12K 5% 1/10W
R431 1-216-107-00 METAL CHIP 270K 5% 1/10W
R432 1-216-025-00 RES-CHIP 100 5% 1/10W
R433 1-216-068-00 METAL CHIP 6.2K 5% 1/10W
R434 1-216-101-00 METAL CHIP 150K 5% 1/10W
R461 1-216-033-00 METAL CHIP 220 5% 1/10W
R462 1-216-033-00 METAL CHIP 220 5% 1/10W
R463 1-216-033-00 METAL CHIP 220 5% 1/10W
R464 1-216-033-00 METAL CHIP 220 5% 1/10W
R465 1-216-033-00 METAL CHIP 220 5% 1/10W
R466 1-216-081-00 METAL CHIP 22K 5% 1/10W
R467 1-217-671-11 METAL CHIP 1 5% 1/10W
R468 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R469 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R470 1-216-081-00 METAL CHIP 22K 5% 1/10W
POWER TC
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
To Next Page
