Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R471 1-216-081-00 METAL CHIP 22K 5% 1/10W
R472 1-216-081-00 METAL CHIP 22K 5% 1/10W
R473 1-216-081-00 METAL CHIP 22K 5% 1/10W
< VARIABLE RESISTOR >
RV401 1-241-765-11 RES, ADJ, CARBON 22K
RV402 1-241-765-11 RES, ADJ, CARBON 22K
RV403 1-241-767-21 RES, ADJ, CARBON 100K
RV421 1-241-765-11 RES, ADJ, CARBON 22K
RV422 1-241-765-11 RES, ADJ, CARBON 22K
RV423 1-241-767-21 RES, ADJ, CARBON 100K
< TRANSFORMER >
T401 1-419-080-11 COIL
T421 1-419-080-11 COIL
T461 1-419-081-11 TRANSFORMER, BIAS OSCILLATION
************************************************************
MISCELLANEOUS
**************
11 1-772-645-11 DECK, MECHANICAL (TCM)
57 1-791-437-12 WIRE (FLAT TYPE) (FFC) (17 CORE) (23cm)
58 1-791-438-12 WIRE (FLAT TYPE) (FFC) (21 CORE)
62 1-418-692-31 INDICATOR BLOCK, LED
(DECK-A CASSETTE HOLDER BACK LIGHT)
66 1-792-835-11 WIRE (FLAT TYPE) (23 CORE)
71 1-418-693-31 INDICATOR BLOCK, LED
(DECK-B CASSETTE HOLDER BACK LIGHT)
101 1-792-834-11 WIRE (FLAT TYPE) (19 CORE)
104 1-678-414-11 PWB, RETAINER
106 A-4303-600-A TUNER PACK (TCB-020) (AEP, UK, AUS)
106 A-4303-604-A TUNER PACK (TCB-020N) (EA)
108 1-792-832-11 WIRE (FLAT TYPE) (14 CORE)
109 1-792-833-11 WIRE (FLAT TYPE) (17 CORE) (22cm)
0114 1-690-608-11 CORD, POWER (AUS)
0114 1-696-169-11 CORD, POWER (AEP, UK)
0114 1-696-169-21 CORD, POWER (EA)
0115 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK)
0203 8-848-483-05 OPTICAL PICK-UP KSM-213CKP/K1N
M901 A-4672-891-A MOTOR (LD) ASSY (LOADING)
0T901 1-435-386-11 TRANSFORMER, POWER (AEP, UK, AUS)
0T901 1-435-628-11 TRANSFORMER, POWER (EA)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-546-14 SCREW +BTP 3X8 TYPE2 N-S
#2 7-685-245-19 SCREW +KTP 3X6 TYPE2 NON-SLIT
#3 7-685-246-14 SCREW +KTP 3X8 TYPE2 NON-SLIT
#4 7-685-659-14 SCREW +BVTP 4X8 TYPE2 N-S
#5 7-685-544-19 SCREW +BTP 3X5 TYPE2 N-S
#6 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
#7 7-621-255-32 SCREW +P 2X5
#8 7-685-536-14 SCREW +BTP 2.6X12 TYPE2 N-S
TC
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
