Sony HCD-D790 - Page 56

— 82 —
1 2 3 4 5 6 7 8
OVER LOAD DET
F/F
OFFSET DET
LATCH/
AUTORESET
V
CC ON
MUTE
AC OFF
DET
V
CC
IC281 UPC1237HA
IC901 LA5617
ON/OFF
CURRENT
LIMITER
START
CIRCUIT
VREF
OVER HEAT
PROTECT
ON/OFF
CURRENT
LIMITER
1
2 3
4
5 6 7 8 9
10
VCC
VMUTE VCC
VREF
ERROR
AMP
VREF
ERROR
AMP
VO1 VCC CN1
EN
EN DISPLAY
GND
NC
CN2
VEE
VO2
~_
1.8V
~_
140uA
COMPARATER
IIC1502 LB1641
1
2 3
4
5 6 7 8 9
10
GND
MOTOR
DRIVE
NOISE
FILTER
CLAMP
FWD.IN
REV.IN
VCC 1 VCC 2
NOISE
FILTER
MOTOR
DRIVE
MOTOR
DRIVE
MOTOR
DRIVE
T.S.D O.C.P
FWD/REV/STOP
CONTROL LOGIC
