Sony HCD-D790 - Back Panel

— 6 —
– BACK PANEL –
⁄‚⁄
⁄‚‡
⁄‚fl
⁄‚fi
⁄‚›
⁄‚¤
⁄‚‹
IN
OUT
XB33/XB44/XB50/XB60 MODEL
⁄‚⁄ ANTENNA terminal
⁄‚¤ VOLTAGE SELECTOR switch (E, AR model)
⁄‚‹ SPEAKER terminal
⁄‚› SURROUND SPEAKER terminal (D790/XB33/XB50/XB60 model)
⁄‚fi VIDEO/MD (AUDIO) jack
⁄‚fl PHONO jack
⁄‚‡ CD DIGITAL OUT connector (XB33/XB44/XB50/XB60 model)
