Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 97 —
R612 1-249-409-11 CARBON 220 5% 1/4W
! R621 1-212-851-00 FUSIBLE 5.6 5% 1/4W F
! R622 1-212-851-00 FUSIBLE 5.6 5% 1/4W F
R623 1-249-432-11 CARBON 18K 5% 1/4W
R624 1-249-432-11 CARBON 18K 5% 1/4W
R625 1-249-429-11 CARBON 10K 5% 1/4W
R651 1-247-856-00 CARBON 11K 5% 1/4W
R652 1-247-856-00 CARBON 11K 5% 1/4W
R653 1-249-441-11 CARBON 100K 5% 1/4W
< VARIABLE RESISTOR >
RV301 1-238-598-11 RES, ADJ, CARBON 2.2K
RV311 1-238-598-11 RES, ADJ, CARBON 2.2K
RV341 1-238-551-11 RES, ADJ, CARBON 220K
RV401 1-238-598-11 RES, ADJ, CARBON 2.2K
RV411 1-238-598-11 RES, ADJ, CARBON 2.2K
RV441 1-238-551-11 RES, ADJ, CARBON 220K
RV651 1-238-599-11 RES, ADJ, CARBON 4.7K
RV652 1-238-599-11 RES, ADJ, CARBON 4.7K
< TRANSFORMER >
T621 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
************************************************************
* A-4699-522-A BD BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-126-607-11 ELECT CHIP 47uF 20% 4V
C102 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C103 1-164-346-11 CERAMIC CHIP 1uF 16V
C105 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C106 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C107 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C108 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C109 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C110 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V
C111 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C112 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C113 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C114 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C115 1-126-607-11 ELECT CHIP 47uF 20% 4V
C116 1-163-016-00 CERAMIC CHIP 0.0039uF 10% 50V
C117 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C118 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C119 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C120 1-124-779-00 ELECT CHIP 10uF 20% 16V
C121 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C122 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C123 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C124 1-126-607-11 ELECT CHIP 47uF 20% 4V
C125 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C126 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C127 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C128 1-163-135-00 CERAMIC CHIP 560PF 5% 50V
C129 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C130 1-164-336-11 CERAMIC CHIP 0.33uF 25V
C131 1-164-346-11 CERAMIC CHIP 1uF 16V
C140 1-110-501-11 CERAMIC CHIP 0.33uF 50V
C154 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C161 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C162 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C163 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C164 1-163-145-00 CERAMIC CHIP 0.0015uF 5% 50V
C165 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C166 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C167 1-163-121-00 CERAMIC CHIP 150PF 5% 50V
C168 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C169 1-163-121-00 CERAMIC CHIP 150PF 5% 50V
C170 1-163-099-00 CERAMIC CHIP 18PF 5% 50V
C171 1-163-237-11 CERAMIC CHIP 27PF 5% 50V
C173 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C174 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C175 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C176 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C177 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C178 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C179 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C181 1-126-205-11 ELECT CHIP 47uF 20% 6.3V
C182 1-126-393-11 ELECT 33uF 20% 10V
C183 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C185 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C188 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C189 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
< CONNECTOR >
CNU101 1-770-014-11 CONNECTOR, FFC/FPC 16P
CNU102 1-778-874-11 CONNECTOR, FFC (LIF (NON-ZIF)) 19P
< FERRITE BEAD >
FB101 1-414-234-11 INDUCTOR, FERRITE BEAD
FB103 1-414-234-11 INDUCTOR, FERRITE BEAD
< IC >
IC101 8-752-080-62 IC CXA1992AR
IC102 8-759-429-32 IC BA5941FP-E2
IC103 8-752-378-66 IC CXD2519Q
< JUMPER RESISTOR >
JW101 1-216-295-91 CONDUCTOR, CHIP (2012)
JW104 1-216-295-91 CONDUCTOR, CHIP (2012)
< TRANSISTOR >
Q101 8-729-010-08 TRANSISTOR MSB710-R
< RESISTOR >
R102 1-216-001-00 METAL CHIP 10 5% 1/10W
R104 1-216-093-00 METAL CHIP 68K 5% 1/10W
R105 1-216-088-00 METAL CHIP 43K 5% 1/10W
R106 1-216-088-00 METAL CHIP 43K 5% 1/10W
R107 1-216-088-00 METAL CHIP 43K 5% 1/10W
AUDIO BD
Note:
The components identi-
fied by mark ! or dotted
line with mark ! are criti-
cal for safety.
Replace only with part
number specified.
Note:
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro
spécifié.
