Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 103 —
Q251 8-729-029-86 TRANSISTOR DTC124ESA-TP
(D790/XB44/XB60)
Q252 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q253 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q254 8-729-141-30 TRANSISTOR 2SC3623ATP-LK
Q281 8-729-029-86 TRANSISTOR DTC124ESA-TP
Q282 8-729-029-40 TRANSISTOR DTA124ESA-TP
Q283 8-729-029-86 TRANSISTOR DTC124ESA-TP
Q301 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q901 8-729-040-20 TRANSISTOR RT1P137L-TP
Q902 8-729-029-86 TRANSISTOR DTC124ESA-TP
Q903 8-729-026-68 TRANSISTOR 2SD2525(TP)
Q904 8-729-030-19 TRANSISTOR 2SB1640(TP)
Q905 8-729-040-20 TRANSISTOR RT1P137L-TP
Q906 8-729-029-40 TRANSISTOR DTA124ESA-TP
Q907 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q1531 8-729-801-93 TRANSISTOR 2SD1387-34-TP
Q1532 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q1533 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q1534 8-729-119-77 TRANSISTOR 2SA1175TP-FEK
Q1535 8-729-029-66 TRANSISTOR DTC114ESA-TP
< RESISTOR >
R101 1-249-417-11 CARBON 1K 5% 1/4W F
(XB50/XB60)
R102 1-249-417-11 CARBON 1K 5% 1/4W F
R103 1-249-437-11 CARBON 47K 5% 1/4W
R104 1-249-417-11 CARBON 1K 5% 1/4W F
R105 1-247-897-11 CARBON 560K 5% 1/4W
R106 1-249-437-11 CARBON 47K 5% 1/4W
R107 1-249-417-11 CARBON 1K 5% 1/4W F
R108 1-249-441-11 CARBON 100K 5% 1/4W
R109 1-247-815-91 CARBON 220 5% 1/4W
(XB50/XB60)
R121 1-249-424-11 CARBON 3.9K 5% 1/4W F
R122 1-247-887-00 CARBON 220K 5% 1/4W
R123 1-249-426-11 CARBON 5.6K 5% 1/4W
(XB33/XB44/XB50/XB60)
R124 1-249-429-11 CARBON 10K 5% 1/4W
(XB33/XB44/XB50/XB60)
R125 1-249-441-11 CARBON 100K 5% 1/4W
(XB33/XB44/XB50/XB60)
R126 1-249-417-11 CARBON 1K 5% 1/4W F
(XB33/XB44/XB50/XB60)
R127 1-249-441-11 CARBON 100K 5% 1/4W
(XB33/XB44/XB50/XB60)
R131 1-260-076-11 CARBON 10 5% 1/2W
(XB50/XB60)
R132 1-260-076-11 CARBON 10 5% 1/2W
(XB50/XB60)
R133 1-260-091-11 CARBON 220 5% 1/2W
R134 1-260-091-11 CARBON 220 5% 1/2W
R140 1-249-429-11 CARBON 10K 5% 1/4W
R141 1-249-437-11 CARBON 47K 5% 1/4W
R142 1-249-429-11 CARBON 10K 5% 1/4W
! R147 1-215-893-11 METAL OXIDE 1.5K 5% 2W F
(D390/D790/G5500/XB60)
! R147 1-216-457-00 METAL OXIDE 1.2K 5% 2W F
(XB33/XB50)
! R147 1-216-458-11 METAL OXIDE 1.8K 5% 2W F
(XB44)
R151 1-249-417-11 CARBON 1K 5% 1/4W F
(XB50/XB60)
R152 1-249-417-11 CARBON 1K 5% 1/4W F
R153 1-249-437-11 CARBON 47K 5% 1/4W
R154 1-249-417-11 CARBON 1K 5% 1/4W F
R155 1-247-897-11 CARBON 560K 5% 1/4W
R156 1-249-437-11 CARBON 47K 5% 1/4W
R157 1-249-417-11 CARBON 1K 5% 1/4W F
R158 1-249-441-11 CARBON 100K 5% 1/4W
R159 1-247-815-91 CARBON 220 5% 1/4W
(XB50/XB60)
R171 1-249-424-11 CARBON 3.9K 5% 1/4W F
R172 1-247-887-00 CARBON 220K 5% 1/4W
R173 1-249-426-11 CARBON 5.6K 5% 1/4W
(XB33/XB44/XB50/XB60)
R174 1-249-429-11 CARBON 10K 5% 1/4W
(XB33/XB44/XB50/XB60)
R176 1-249-417-11 CARBON 1K 5% 1/4W F
(XB33/XB44/XB50/XB60)
R177 1-249-441-11 CARBON 100K 5% 1/4W
(XB33/XB44/XB50/XB60)
R181 1-260-076-11 CARBON 10 5% 1/2W
(XB50/XB60)
R182 1-260-076-11 CARBON 10 5% 1/2W
(XB50/XB60)
R183 1-260-091-11 CARBON 220 5% 1/2W
R184 1-260-091-11 CARBON 220 5% 1/2W
R191 1-249-425-11 CARBON 4.7K 5% 1/4W F
(XB44)
R192 1-249-441-11 CARBON 100K 5% 1/4W
(XB44)
R193 1-249-421-11 CARBON 2.2K 5% 1/4W F
(XB44)
R194 1-249-437-11 CARBON 47K 5% 1/4W
(XB44)
R195 1-249-437-11 CARBON 47K 5% 1/4W
(XB44)
R201 1-249-429-11 CARBON 10K 5% 1/4W
R202 1-247-863-91 CARBON 22K 5% 1/4W
R203 1-249-441-11 CARBON 100K 5% 1/4W
R205 1-247-863-91 CARBON 22K 5% 1/4W
R206 1-249-421-11 CARBON 2.2K 5% 1/4W F
R207 1-249-431-11 CARBON 15K 5% 1/4W
R209 1-249-441-11 CARBON 100K 5% 1/4W
R210 1-247-891-00 CARBON 330K 5% 1/4W
(XB50)
R210 1-247-896-11 CARBON 510K 5% 1/4W
(EXCEPT XB50)
R211 1-247-891-00 CARBON 330K 5% 1/4W
(D790/XB44/XB60)
R211 1-249-441-11 CARBON 100K 5% 1/4W
(XB50)
R212 1-247-826-00 CARBON 620 5% 1/4W
(EXCEPT XB50)
R212 1-249-411-11 CARBON 330 5% 1/4W
(XB50)
R213 1-249-429-11 CARBON 10K 5% 1/4W
R214 1-249-437-11 CARBON 47K 5% 1/4W
R215 1-247-903-00 CARBON 1M 5% 1/4W
R216 1-249-429-11 CARBON 10K 5% 1/4W
R217 1-249-437-11 CARBON 47K 5% 1/4W
R221 1-249-425-11 CARBON 4.7K 5% 1/4W F
R222 1-249-425-11 CARBON 4.7K 5% 1/4W F
MAIN
Note:
The components identi-
fied by mark ! or dotted
line with mark ! are criti-
cal for safety.
Replace only with part
number specified.
Note:
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro
spécifié.
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
