Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 108 —
C901 1-128-493-11 ELECT 4700uF 20% 71V
(XB44)
C902 1-130-777-00 FILM 0.1uF 10% 100V
C951 1-104-482-11 ELECT 4700uF 20% 63V
(D390/D790/G5500/XB60)
C951 1-117-750-11 ELECT 3300uF 20% 63V
(XB33/XB50)
C951 1-128-493-11 ELECT 4700uF 20% 71V
(XB44)
C952 1-130-777-00 FILM 0.1uF 10% 100V
< CONNECTOR >
CN801 1-778-981-11 CONNECTOR, BOARD TO BOARD 13P
< DIODE >
D801 8-719-991-33 DIODE 1SS133T-77
D841 8-719-991-33 DIODE 1SS133T-77
D842 8-719-991-33 DIODE 1SS133T-77
D851 8-719-991-33 DIODE 1SS133T-77
D901 8-719-510-68 DIODE D5SBA204101
< IC >
IC801 8-749-921-68 IC STK4231MK2 (EXCEPT XB50)
IC801 8-749-922-65 IC STK4221MK2 (XB50)
< TRANSISTOR >
Q801 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q851 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
< RESISTOR >
R801 1-249-417-11 CARBON 1K 5% 1/4W F
R802 1-249-437-11 CARBON 47K 5% 1/4W
R803 1-249-413-11 CARBON 470 5% 1/4W F
(EXCEPT XB50)
R803 1-249-414-11 CARBON 560 5% 1/4W F
(XB50)
R804 1-249-437-11 CARBON 47K 5% 1/4W
(EXCEPT XB44)
R804 1-249-438-11 CARBON 56K 5% 1/4W
(XB44)
R805 1-260-107-11 CARBON 4.7K 5% 1/2W
R806 1-260-107-11 CARBON 4.7K 5% 1/2W
! R807 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R808 1-220-893-11 METAL 0.22 10% 5W
R809 1-260-076-11 CARBON 10 5% 1/2W
R811 1-249-417-11 CARBON 1K 5% 1/4W F
R812 1-249-431-11 CARBON 15K 5% 1/4W
R813 1-249-441-11 CARBON 100K 5% 1/4W
R814 1-260-105-11 CARBON 3.3K 5% 1/2W
R816 1-260-105-11 CARBON 3.3K 5% 1/2W
! R820 1-202-972-61 FUSIBLE 1 5% 1/4W F
R841 1-249-426-11 CARBON 5.6K 5% 1/4W
R842 1-247-889-00 CARBON 270K 5% 1/4W
R843 1-249-421-11 CARBON 2.2K 5% 1/4W F
R844 1-249-429-11 CARBON 10K 5% 1/4W
R851 1-249-417-11 CARBON 1K 5% 1/4W F
R852 1-249-437-11 CARBON 47K 5% 1/4W
R853 1-249-413-11 CARBON 470 5% 1/4W F
(EXCEPT XB50)
R853 1-249-414-11 CARBON 560 5% 1/4W F
(XB50)
R854 1-249-437-11 CARBON 47K 5% 1/4W
(EXCEPT XB44)
R854 1-249-438-11 CARBON 56K 5% 1/4W
(XB44)
R855 1-260-107-11 CARBON 4.7K 5% 1/2W
R856 1-260-107-11 CARBON 4.7K 5% 1/2W
! R857 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R858 1-220-893-11 METAL 0.22 10% 5W
R859 1-260-076-11 CARBON 10 5% 1/2W
R861 1-249-417-11 CARBON 1K 5% 1/4W F
R862 1-249-431-11 CARBON 15K 5% 1/4W
R863 1-249-441-11 CARBON 100K 5% 1/4W
************************************************************
1-659-058-13 TABLE SENSOR BOARD
*******************
< IC >
IC202 8-749-924-18 IC PHOTO INTERRUPTER RPI-1391
< RESISTOR >
R207 1-249-416-11 CARBON 820 5% 1/4W
************************************************************
* 1-664-012-11 TC-A SW BOARD
**************
< CONNECTOR >
* CN612 1-568-943-11 PIN, CONNECTOR 5P
< DIODE >
D631 8-719-057-10 DIODE LNJ301MPUJAB (·)
D632 8-719-057-10 DIODE LNJ301MPUJAB (ª)
< RESISTOR >
R705 1-249-415-11 CARBON 680 5% 1/4W F
R706 1-249-416-11 CARBON 820 5% 1/4W F
R707 1-249-418-11 CARBON 1.2K 5% 1/4W F
R708 1-249-419-11 CARBON 1.5K 5% 1/4W F
R709 1-249-421-11 CARBON 2.2K 5% 1/4W F
R710 1-247-843-11 CARBON 3.3K 5% 1/4W
R711 1-247-807-31 CARBON 100 5% 1/4W
R714 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S641 1-554-303-21 SWITCH, TACTILE (·)
S642 1-554-303-21 SWITCH, TACTILE (ª)
S643 1-554-303-21 SWITCH, TACTILE (p)
S644 1-554-303-21 SWITCH, TACTILE (0)
S645 1-554-303-21 SWITCH, TACTILE ())
S646 1-554-303-21 SWITCH, TACTILE (DOLBY NR)
S647 1-554-303-21 SWITCH, TACTILE (DIRECTION)
************************************************************
POWER AMP TABLE SENSOR TC-A SW
Note:
The components identi-
fied by mark ! or dotted
line with mark ! are criti-
cal for safety.
Replace only with part
number specified.
Note:
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro
spécifié.
