Sony HCD-D890AV - Page 26

– 32 –
IC103 @¶ MDP
1
2
3
4
5
WAVEFORMS
– CD SECTION –
IC101 #£ RFO
IC101 2 FEI
IC101 $¶ TEI
IC103 ^™ RFCK
6
IC103 ^º XPCK
7
IC103 &¢ WFCK
IC103 *ª XTAI
8
500mV/DIV, 500nsec/DIV
1.3Vp-p
200mV/DIV, 1µsec/DIV
0.5Vp-p
50mV/DIV, 1msec/DIV
0.2Vp-p
7.8µsec
2.5Vp-p
230µsec
5Vp-p
135µsec
5Vp-p
135µsec
5Vp-p
16.9344MHz
2.6Vp-p
1
2
IC1752 !¢
IC21 @¢ XOUT
– TUNER SECTION –
(AEP, UK, German model)
4.332MHz
2Vp-p
1
IC21 @¢ XOUT
– TUNER SECTION –
(East European, CIS model)
4.5MHz
4.2Vp-p
1
IC601 !™ X-OUT
– DISPLAY SECTION –
1
IC602 @¢ XTAL
– MAIN SECTION (1/5) –
4.5MHz
4.2Vp-p
1
2
IC701 !£ XT2
IC701 0 X2
– MAIN SECTION (2/5) –
8MHz
4.8Vp-p
32.768kHz
5.2Vp-p
8MHz
4Vp-p
8MHz
5.5Vp-p
