Sony HCD-D890AV - Tape Mechanism Deck; Cassette Lid Assembly

– 7 –
2-3. TAPE MECHANISM DECK
2-4. CASSETTE LID ASSEMBLY
3 Two brackets.
2 Two screws (BVTP2.6x8)
1 Two springs.
4 Cassette lid assembly
A
4
Three screws (BVTP2.6x8)
3 Three screws (BVTP2.6x8)
5 Remove the tape mechanism deck
section to direction of arrow
A .
2 Open the cassette lid.
1 Push the two buttons.
