– 126 –
< IC >
IC21 8-759-288-54 IC LC72130
IC41 8-759-495-82 IC LA1838
IC1701 8-759-063-04 IC IR3R42
IC1702 8-759-140-53 IC uPD4053BC
< IFT >
IFT41 1-409-636-11 TRANSFORMER, IF (CERAMIC FILTER)
< JUMPER RESISTOR >
JR2 1-216-295-91 METAL CHIP 0 5% 1/10W
JR6 1-216-295-91 METAL CHIP 0 5% 1/10W
JR8 1-216-295-91 METAL CHIP 0 5% 1/10W
JR9 1-216-295-91 METAL CHIP 0 5% 1/10W
JR12 1-216-296-91 METAL CHIP 0 5% 1/8W
JR46 1-216-296-91 METAL CHIP 0 5% 1/8W
JR47 1-216-295-91 METAL CHIP 0 5% 1/10W
JR48 1-216-295-91 METAL CHIP 0 5% 1/10W
JR49 1-216-296-91 METAL CHIP 0 5% 1/8W
JR51 1-216-295-91 METAL CHIP 0 5% 1/10W
JR52 1-216-295-91 METAL CHIP 0 5% 1/10W
JR53 1-216-296-91 METAL CHIP 0 5% 1/8W
JR54 1-216-295-91 METAL CHIP 0 5% 1/10W
JR1701 1-216-295-91 METAL CHIP 0 5% 1/10W
JR1702 1-216-295-91 METAL CHIP 0 5% 1/10W
JR1703 1-216-295-91 METAL CHIP 0 5% 1/10W
JR1704 1-216-295-91 METAL CHIP 0 5% 1/10W
JR1705 1-216-295-91 METAL CHIP 0 5% 1/10W
< COIL >
L3 1-410-521-11 MICRO INDUCTOR 100uH
L41 1-407-500-00 MICRO INDUCTOR 4.7mH
L1701 1-409-497-11 COIL (FILTER)
< FILTER >
LPF41 1-239-845-11 FILTER, LOW PASS
LPF42 1-239-845-11 FILTER, LOW PASS
< TRANSISTOR >
Q1 8-729-201-27 TRANSISTOR 2SC2715Y
Q2 8-729-201-27 TRANSISTOR 2SC2715Y
Q3 8-729-201-27 TRANSISTOR 2SC2715Y
Q4 8-729-201-27 TRANSISTOR 2SC2715Y
Q5 8-729-216-22 TRANSISTOR MUN2111
Q9 8-729-216-22 TRANSISTOR 2SA812-M5M6
Q11 8-729-421-22 TRANSISTOR MUN2211
Q12 8-729-421-22 TRANSISTOR MUN2211
Q13 8-729-421-22 TRANSISTOR MUN2211
Q14 8-729-421-22 TRANSISTOR MUN2211
Q1701 8-729-424-08 TRANSISTOR MUN2111
Q1702 8-729-027-43 TRANSISTOR RT1N141C
Q1703 8-729-421-22 TRANSISTOR MUN2211
< RESISTOR >
R1 1-249-401-11 CARBON 47 5% 1/4W F
R2 1-216-037-00 METAL CHIP 330 5% 1/10W
Ref. No. Part No. Description Remark
TCB
R3 1-216-037-00 METAL CHIP 330 5% 1/10W
R5 1-216-037-00 METAL CHIP 330 5% 1/10W
R6 1-216-081-00 METAL CHIP 22K 5% 1/10W
R7 1-216-037-00 METAL CHIP 330 5% 1/10W
R8 1-216-037-00 METAL CHIP 330 5% 1/10W
R9 1-216-081-00 METAL CHIP 22K 5% 1/10W
R10 1-216-037-00 METAL CHIP 330 5% 1/10W
R11 1-216-081-00 METAL CHIP 22K 5% 1/10W
R12 1-216-037-00 METAL CHIP 330 5% 1/10W
R13 1-216-037-00 METAL CHIP 330 5% 1/10W
R14 1-216-081-00 METAL CHIP 22K 5% 1/10W
R18 1-216-073-00 METAL CHIP 10K 5% 1/10W
R19 1-216-073-00 METAL CHIP 10K 5% 1/10W
R21 1-249-417-11 CARBON 1.0K 5% 1/4W
R22 1-249-417-11 CARBON 1.0K 5% 1/4W
R23 1-249-417-11 CARBON 1.0K 5% 1/4W
R24 1-247-807-31 CARBON 100 5% 1/4W
R25 1-249-417-11 CARBON 1.0K 5% 1/4W F
R26 1-249-437-11 CARBON 47K 5% 1/4W
R27 1-249-429-11 CARBON 10K 5% 1/4W
R28 1-249-417-11 CARBON 1.0K 5% 1/4W F
R29 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R30 1-216-186-00 METAL CHIP 330 5% 1/8W
R31 1-216-025-91 METAL CHIP 100 5% 1/10W
R32 1-249-425-11 CARBON 4.7K 5% 1/4W F
R33 1-249-425-11 CARBON 4.7K 5% 1/4W F
R34 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R35 1-216-214-00 METAL CHIP 4.7K 5% 1/8W
R36 1-216-025-91 METAL CHIP 100 5% 1/10W
R37 1-216-073-00 METAL CHIP 10K 5% 1/10W
R38 1-216-089-91 METAL CHIP 47K 5% 1/10W
R39 1-249-429-11 CARBON 10K 5% 1/4W
R41 1-216-013-00 METAL CHIP 33 5% 1/10W
R42 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R43 1-216-037-00 METAL CHIP 330 5% 1/10W
R44 1-216-001-00 METAL CHIP 10 5% 1/10W
R45 1-247-843-11 CARBON 3.3K 5% 1/4W F
R46 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R47 1-216-097-91 METAL CHIP 100K 5% 1/10W
R48 1-249-417-11 CARBON 1.0K 5% 1/4W F
R49 1-216-049-91 METAL CHIP 1.0K 5% 1/10W
R50 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R51 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R52 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R53 1-216-061-00 METAL CHIP 3.3K 5% 1/4W
R54 1-216-073-00 METAL CHIP 10K 5% 1/10W
R55 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R57 1-216-162-00 METAL CHIP 33 5% 1/8W
R58 1-216-013-00 METAL CHIP 33 5% 1/10W
R91 1-216-295-91 METAL CHIP 0 5% 1/10W
R92 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1701 1-216-081-00 METAL CHIP 22K 5% 1/10W
R1702 1-216-085-00 METAL CHIP 33K 5% 1/10W
R1703 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R1704 1-216-076-00 METAL CHIP 13K 5% 1/10W
R1705 1-216-049-91 METAL CHIP 1.0K 5% 1/10W
R1706 1-216-049-91 METAL CHIP 1.0K 5% 1/10W
Ref. No. Part No. Description Remark
