– 128 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
TC-A
TC-B
R706 1-249-425-11 CARBON 4.7K 5% 1/4W F
R707 1-247-804-11 CARBON 75 5% 1/4W
R708 1-247-804-11 CARBON 75 5% 1/4W
< SWITCH >
S641 1-554-303-21 SWITCH, TACTILE (·)
S642 1-554-303-21 SWITCH, TACTILE (ª)
S643 1-554-303-21 SWITCH, TACTILE (π)
S644 1-554-303-21 SWITCH, TACTILE (º)
S645 1-554-303-21 SWITCH, TACTILE (‚)
S646 1-554-303-21 SWITCH, TACTILE (DOLBY ON)
S647 1-554-303-21 SWITCH, TACTILE (DIRECTION)
**************************************************************
* 1-672-194-11 TC-B BOARD
**********
< DIODE >
D635 8-719-058-03 DIODE SEL5423E-TP15 (ª)(B DECK)
D636 8-719-058-03 DIODE SEL5423E-TP15 (·)(B DECK)
D637 8-719-057-97 DIODE SEL5923A-TP15 (P)
D638 8-719-058-04 DIODE SEL5223S-TP15 (r REC)
< RESISTOR >
R711 1-249-410-11 CARBON 270 5% 1/4W F
R712 1-249-411-11 CARBON 330 5% 1/4W
R713 1-249-413-11 CARBON 470 5% 1/4W F
R714 1-249-414-11 CARBON 560 5% 1/4W F
R715 1-249-415-11 CARBON 680 5% 1/4W F
R716 1-249-417-11 CARBON 1K 5% 1/4W F
R717 1-249-418-11 CARBON 1.2K 5% 1/4W F
R718 1-249-420-11 CARBON 1.8K 5% 1/4W F
R719 1-249-422-11 CARBON 2.7K 5% 1/4W F
R720 1-247-804-11 CARBON 75 5% 1/4W
R721 1-247-804-11 CARBON 75 5% 1/4W
R722 1-247-807-31 CARBON 100 5% 1/4W
R723 1-249-407-11 CARBON 150 5% 1/4W F
< SWITCH >
S651 1-554-303-21 SWITCH, TACTILE (·)
S652 1-554-303-21 SWITCH, TACTILE (ª)
S653 1-554-303-21 SWITCH, TACTILE (π)
S654 1-554-303-21 SWITCH, TACTILE (º)
S655 1-554-303-21 SWITCH, TACTILE (‚)
S656 1-554-303-21 SWITCH, TACTILE (P)
S657 1-554-303-21 SWITCH, TACTILE (r REC)
S658 1-554-303-21 SWITCH, TACTILE (HI-SPEED DUB)
S659 1-554-303-21 SWITCH, TACTILE (CD SYNCHRO)
**************************************************************
* 1-672-431-11 TRANS BOARD (DR4/DR5/DR6/DR440)
***********
* 1-672-430-11 TRANS BOARD (W300/W5000/XB500)
***********
< CAPACITOR >
C843 1-130-777-00 FILM 0.1uF 10% 100V
TABLE SENSOR
S1002 1-570-953-11 SWITCH, PUSH (1 KEY)
S1003 1-771-333-11 SWITCH, LEAF (A PLAY)
S1004 1-771-205-11 SWITCH, LEAF (B PLAY)
S1005 1-771-205-11 SWITCH, LEAF (A 120/70)
S1006 1-771-333-11 SWITCH, LEAF (REC A)
S1008 1-771-205-11 SWITCH, LEAF (REC B)
S1009 1-771-205-11 SWITCH, LEAF (B 120/70)
**************************************************************
* 1-672-432-11 SUB TRANS BOARD (W300/W5000/XB500)
***************
< CAPACITOR >
!C901 1-113-925-11 CERAMIC 0.01uF 20% 250V
< CONNECTOR >
* CN901 1-580-230-11 PIN CONNECTOR (PC BOARD) 2P
(W300/W5000/XB500)
CN902 1-564-321-00 PIN, CONNECTOR 2P (W300/W5000/XB500)
< DIODE >
D901 8-719-991-33 DIODE 1SS133T-77 (W300/W5000/XB500)
< RELAY >
!RY901 1-755-276-11 RELAY, POWER (W300/W5000/XB500)
!RY901 1-755-276-21 RELAY, POWER (XB500)
!RY901 1-755-276-31 RELAY, POWER (XB500)
< TRANSFORMER >
T901 1-433-615-11 TRANSFORMER, POWER (W300/W5000)
T901 1-433-616-11 TRANSFORMER, POWER (XB500)
**************************************************************
* 1-659-058-13 TABLE SENSOR BOARD
******************
< IC >
IC202 8-749-924-18 IC PHOTO INTERRUPTER RPI-1391
< RESISTOR >
R207 1-249-416-11 CARBON 820 5% 1/4W F
**************************************************************
* 1-672-193-11 TC-A BOARD
**********
< DIODE >
D631 8-719-058-03 DIODE SEL5423E-TP15 (·)(A DECK)
D632 8-719-058-03 DIODE SEL5423E-TP15 (ª)(A DECK)
< RESISTOR >
R701 1-249-417-11 CARBON 1K 5% 1/4W F
R702 1-249-418-11 CARBON 1.2K 5% 1/4W F
R703 1-249-420-11 CARBON 1.8K 5% 1/4W F
R704 1-249-422-11 CARBON 2.7K 5% 1/4W F
R705 1-247-843-11 CARBON 3.3K 5% 1/4W
SUB TRANS
LEAF SW
TRANS
