– 129 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
TRANS
C893 1-130-777-00 FILM 0.1uF 10% 100V
C961 1-162-306-11 CERAMIC 0.01uF 20% 16V
C963 1-162-306-11 CERAMIC 0.01uF 20% 16V
< CONNECTOR >
* CN901 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
(DR4:E,TH,EA,SP,AR/DR5:E,SP,AR/DR6:E,SP,MY,AR)
* CN952 1-564-526-11 PLUG, CONNECTOR 11P (W300/W5000/XB500)
* CN952 1-564-528-11 PLUG, CONNECTOR 13P (DR4/DR5/DR6/DR440)
< DIODE >
D832 8-719-510-68 DIODE D5SBA20F01
< FUSE >
!F951 1-533-310-11 FUSE, GLASS TUBE6.3A 125V
!F951 1-532-505-31 FUSE (T5AL/250V)(DR4/DR440)
!F951 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG)
!F961 1-532-506-31 FUSE (T6.3AL/250V)
(DR4/DR5/DR6/DR440/XB500)
!F962 1-532-506-31 FUSE (T6.3AL/250V)
(DR4/DR5/DR6/DR440/XB500)
!F963 1-532-506-31 FUSE (T6.3AL/250V)
(DR4/DR5/DR6/DR440/XB500)
!F964 1-532-506-31 FUSE (T6.3AL/250V)
(DR4/DR5/DR6/DR440/XB500)
< FUSE HOLDER >
FH951 1-533-233-21 HOLDER, FUSE
(DR4:E,TH,EA,SP,AR,MX/DR5/DR6/DR440/W300/W5000)
FH952 1-533-233-21 HOLDER, FUSE
(DR4:E,TH,EA,SP,AR,MX/DR5/DR6/DR440/W300/W5000)
FH961 1-533-233-21 HOLDER, FUSE (DR4/DR5/DR6/DR440/XB500)
FH962 1-533-233-21 HOLDER, FUSE (DR4/DR5/DR6/DR440/XB500)
FH963 1-533-233-21 HOLDER, FUSE (DR4/DR5/DR6/DR440/XB500)
FH964 1-533-233-21 HOLDER, FUSE (DR4/DR5/DR6/DR440/XB500)
FH965 1-533-233-21 HOLDER, FUSE (DR4/DR5/DR6/DR440/XB500)
FH966 1-533-233-21 HOLDER, FUSE (DR4/DR5/DR6/DR440/XB500)
FH967 1-533-233-21 HOLDER, FUSE (DR4/DR5/DR6/DR440/XB500)
FH968 1-533-233-21 HOLDER, FUSE (DR4/DR5/DR6/DR440/XB500)
< RESISTOR >
R951 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
(W300:CND)
R952 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
(W300:CND)
R961 1-202-725-00 SOLID 3.3M 10% 1/2W
(W300:CND)
R961 1-219-237-11 SOLID 3.3M 20% 1/2W
(W300:US/W5000)
< TRANSFORMER >
!T951 1-433-602-11 TRANSFORMER, POWER (W300/W5000)
!T951 1-433-603-11 TRANSFORMER, POWER (XB500)
!T951 1-433-604-11 TRANSFORMER, POWER (DR4/DR440)
!T951 1-433-606-11 TRANSFORMER, POWER (DR5)
!T951 1-433-611-11 TRANSFORMER, POWER (DR6)
**************************************************************
MISCELLANEOUS
*************
1 1-769-977-11 WIRE (FLAT TYPE) (13 CORE)
1 1-773-009-11 WIRE (FLAT TYPE) (15 CORE)(XB500)
5 1-233-545-11 TUNER (UNIT)(EA,SP,MY,AR,MX,AUS)
5 1-693-443-11 TUNER (UNIT)(AEP,UK)
5 1-693-445-11 TUNER (UNIT)(US,CND)
5 1-693-453-11 TUNER (UNIT)(E,TH)
61 1-773-002-11 WIRE (FLAT TYPE) (15 CORE) (80 mm)
62 1-773-034-11 WIRE (FLAT TYPE) (15 CORE) (420 mm)
156 1-790-287-11 WIRE (FLAT TYPE) (19 CORE)
160 1-773-006-11 WIRE (FLAT TYPE) (15 CORE)
161 1-773-056-11 WIRE (FLAT TYPE) (17 CORE)
507 1-452-925-21 MAGNET ASSY
!601 8-820-020-02 OPTICAL PICK-UP KSS-213D/Q-NP
602 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
!CNP901 1-558-943-41 CORD, POWER (E,MX,TH)
!CNP901 1-575-042-21 CORD, POWER (CND)
!CNP901 1-575-651-21 CORD, POWER (AEP,UK,EA,SP,MY)
!CNP901 1-696-845-31 CORD, POWER (AUS)
!CNP901 1-783-531-31 CORD, POWER (US)
!CNP901 1-783-941-31 CORD, POWER (AR)
FL601 1-517-840-11 INDICATOR TUBE, FLUORESCENT
HP101 A-2056-681-B DECK (A) ASSY, HEAD (230AWR2)
HP101 A-2056-683-B DECK (A) ASSY, HEAD (230PWR2)
HRPE101 A-2056-682-B DECK (B) ASSY, HEAD (230AWR2)
HRPE101 A-2056-684-B DECK (B) ASSY, HEAD (230PWR2)
M1 A-2004-628-A MOTOR ASSY, CAPSTAN
M101 X-4917-523-3 MOTOR ASSY (SPINDLE)
M102 X-4917-504-1 MOTOR ASSY (SLED)
M201 A-4660-977-A MOTOR ASSY (TABLE)
M901 1-698-792-11 FAN, DC (DR4/DR440/W300/W5000)
M901 1-763-072-11 FAN, DC (DR5/DR6)
!T901 1-433-615-11 TRANSFORMER, POWER (W300/W5000)
!T901 1-433-616-11 TRANSFORMER, POWER (XB500)
!T951 1-433-602-11 TRANSFORMER, POWER (W300/W5000)
!T951 1-433-603-11 TRANSFORMER, POWER (XB500)
!T951 1-433-604-11 TRANSFORMER, POWER (DR4/DR440)
!T951 1-433-606-11 TRANSFORMER, POWER (DR5)
!T951 1-433-611-11 TRANSFORMER, POWER (DR6)
**************************************************************
ACCESSORIES & PACKING MATERIALS
*******************************
1-475-572-41 COMMANDER, STANDARD (RM-SR5B)
4-988-173-01 COVER, BATTERY (FOR RM-SR5B)
1-501-374-11 ANTENNA, LOOP
1-501-659-41 ANTENNA (FM)
(DR4/DR5/DR6/DR440/W300/W5000)
1-501-804-11 ANTENNA (FM)(XB500)
1-569-008-21 ADAPTOR, CONVERSION 2P (EA,SP,MY)
3-865-548-11 MANUAL, INSTRUCTION (ENGLISH)
3-865-548-21 MANUAL, INSTRUCTION (FRENCH)
(DR4:EA/W300:CND)
3-865-548-31 MANUAL, INSTRUCTION (SPANISH)
(DR4:AR,MX/DR5:AR,MX/DR6:AR,MX/DR440)
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
