64
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C552 1-162-294-31 CERAMIC 0.001uF 10% 50V
C553 1-162-286-31 CERAMIC 220PF 10% 50V
C554 1-104-665-11 ELECT 100uF 20% 10V
C557 1-136-495-11 MYLAR 0.068uF 5% 50V
C558 1-136-495-11 MYLAR 0.068uF 5% 50V
C559 1-128-560-11 ELECT 22uF 20% 100V
C581 1-126-967-11 ELECT 47uF 20% 50V
C591 1-130-777-00 MYLAR 0.1uF 5% 100V
C592 1-127-752-11 ELECT 3300uF 20% 63V
C596 1-127-755-11 ELECT 3300uF 20% 100V
C942 1-126-964-11 ELECT 10uF 20% 50V
C943 1-126-968-11 ELECT 100uF 20% 50V
C980 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN502 1-778-981-11 CONNECTOR, BOARD TO BOARD 13P
CN503 1-778-981-11 CONNECTOR, BOARD TO BOARD 13P
< DIODE >
D501 8-719-911-19 DIODE 1SS133T-72
D502 8-719-911-19 DIODE 1SS133T-72
D503 8-719-922-03 DIODE MTZJ-T-77-18C
D504 8-719-922-03 DIODE MTZJ-T-77-18C
D541 8-719-302-38 DIODE RBV-602-01
D543 8-719-302-38 DIODE RBV-602-01
D551 8-719-911-19 DIODE 1SS133T-72
D581 8-719-911-19 DIODE 1SS133T-72
D941 8-719-110-90 DIODE MTZJ-T-77-39D
D979 8-719-110-31 DIODE MTZJ-T-72-12B
< EARTH TERMINAL >
* EP501 1-537-738-21 TERMINAL, EARTH
< IC >
IC501 8-749-017-06 IC STK412-150
< TRANSISTOR >
Q501 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q503 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q504 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q505 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q506 8-729-119-79 TRANSISTOR 2SC2785TP-FEK
Q551 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q581 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q941 8-729-048-52 TRANSISTOR 2SA1932 (TP)
Q942 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
< RESISTOR >
R501 1-249-417-11 CARBON 1K 5% 1/4W
R502 1-249-438-11 CARBON 56K 5% 1/4W
R503 1-249-412-11 CARBON 390 5% 1/4W
R504 1-249-438-11 CARBON 56K 5% 1/4W
R505 1-249-417-11 CARBON 1K 5% 1/4W
R506 1-249-431-11 CARBON 15K 5% 1/4W
R507 1-249-441-11 CARBON 100K 5% 1/4W
0 R508 1-219-718-11 METAL 0.1 10% 5W F
R509 1-260-076-11 CARBON 10 5% 1/2W
0 R510 1-219-718-11 METAL 0.1 10% 5W F
0 R511 1-212-881-11 FUSIBLE 100 5% 1/4W F
0 R512 1-202-972-61 FUSIBLE 1 5% 1/4W F
R513 1-249-435-11 CARBON 33K 5% 1/4W
R514 1-249-421-11 CARBON 2.2K 5% 1/4W
R515 1-249-433-11 CARBON 22K 5% 1/4W
R516 1-249-429-11 CARBON 10K 5% 1/4W
R517 1-249-421-11 CARBON 2.2K 5% 1/4W
R518 1-249-435-11 CARBON 33K 5% 1/4W
R519 1-249-439-11 CARBON 68K 5% 1/4W
0 R520 1-215-872-11 METAL OXIDE 3.3K 5% 1W F
R521 1-249-441-11 CARBON 100K 5% 1/4W
R522 1-249-441-11 CARBON 100K 5% 1/4W
R523 1-249-441-11 CARBON 100K 5% 1/4W
0 R524 1-215-872-11 METAL OXIDE 3.3K 5% 1W F
R541 1-249-441-11 CARBON 100K 5% 1/4W
R542 1-249-441-11 CARBON 100K 5% 1/4W
R551 1-249-417-11 CARBON 1K 5% 1/4W
R552 1-249-438-11 CARBON 56K 5% 1/4W
R553 1-249-412-11 CARBON 390 5% 1/4W
R554 1-249-438-11 CARBON 56K 5% 1/4W
R555 1-249-417-11 CARBON 1K 5% 1/4W
R556 1-249-431-11 CARBON 15K 5% 1/4W
R557 1-249-441-11 CARBON 100K 5% 1/4W
0 R558 1-219-718-11 METAL 0.1 10% 5W F
R559 1-260-076-11 CARBON 10 5% 1/2W
0 R560 1-219-718-11 METAL 0.1 10% 5W F
0 R561 1-212-881-11 FUSIBLE 100 5% 1/4W F
R581 1-249-435-11 CARBON 33K 5% 1/4W
R582 1-249-435-11 CARBON 33K 5% 1/4W
R591 1-249-441-11 CARBON 100K 5% 1/4W
R592 1-249-441-11 CARBON 100K 5% 1/4W
0 R941 1-216-478-11 METAL OXIDE 390 5% 3W F
R942 1-249-429-11 CARBON 10K 5% 1/4W
R943 1-249-417-11 CARBON 1K 5% 1/4W
R944 1-249-393-11 CARBON 10 5% 1/4W
R980 1-249-429-11 CARBON 10K 5% 1/4W
< THERMISTOR >
TH501 1-807-796-11 THERMISTOR
**************************************************************
1-675-911-11 SENSOR BOARD
**************
< CAPACITOR >
C712 1-164-159-11 CERAMIC 0.1uF 50V
< PHOTO INTERRUPTER >
IC711 8-749-014-38 PHOTO INTERRUPTER SG-264
< RESISTOR >
R711 1-247-876-11 CARBON 75K 5% 1/4W
R712 1-249-409-11 CARBON 220 5% 1/4W
R713 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S711 1-771-821-11 SWITCH, PUSH (1 KEY) (BU UP/DOWN)
**************************************************************
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
POWER AMP SENSOR
To Next Page
