Sony HCD-DX8 - TRANS BOARD PARTS

65
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
1-676-808-11 TRANS BOARD
*************
1-533-293-11 FUSE HOLDER
< CAPACITOR >
0 C972 1-113-925-11 CERAMIC 0.01uF 20% 250V
< CONNECTOR >
CN975 1-564-321-00 PIN, CONNECTOR 2P
* CN977 1-564-528-11 PLUG, CONNECTOR 13P
< FUSE >
0 F971 1-532-506-31 FUSE (T6.3AL/250) (EXCEPT MX, AUS)
0 F974 1-532-506-31 FUSE (T6.3AL/250)
0 F975 1-532-506-31 FUSE (T6.3AL/250)
0 F976 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG) (T8AL/250)
0 F977 1-533-949-31 FUSE, CYLINDRICAL (TIME LUG) (T8AL/250)
< RESISTOR >
0 R951 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
0 R952 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
0 R953 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
< SWITCH >
0 S951 1-771-291-11 SWITCH, POWER (VOLTAGE SELECTOR)
(EXCEPT MX, AUS)
< TRANSFORMER >
0 T971 1-435-325-11 POWER TRANSFORMER
**************************************************************
MISCELLANEOUS
**************
0 10 1-526-794-11 OUTLET, AC
101 1-773-045-11 WIRE (FLAT TYPE) (17 CORE)
104 1-773-122-11 WIRE (FLAT TYPE) (19 CORE)
0 108 1-575-653-11 CORD, POWER (E3)
0 108 1-696-847-11 CORD, POWER (AUS)
0 108 1-777-071-21 CORD, POWER (MY, SP)
0 108 1-777-071-51 CORD, POWER (EA)
0 108 1-783-941-11 CORD, POWER (MX, AR)
0 108 1-791-901-11 CORD, POWER (E2)
0 109 1-569-007-11 ADAPTOR, CONVERSION 2P (E3)
0 109 1-569-008-21 ADAPTOR, CONVERSION (EA, MY, SP)
209 1-791-983-12 WIRE (FLAT TYPE) (8 CORE)
216 1-471-035-11 MAGNET ASSY
0 251 8-820-116-01 OPTICAL PICK UP KSM-213DAP/Z-NP
252 1-792-024-11 WIRE (FLAT TYPE) (16 CORE)
HP901 X-4954-985-1 BLOCK (A) ASSY, HEAD (PB)
HRPE901X-4954-986-1 BLOCK (B) ASSY, HEAD (REC/PB/ERASE)
M721 A-4672-826-A MOTOR ASSY (TURN)
M901 X-3378-241-1 MOTOR ASSY (WITH PULLEY)
(CAPSTAN/REEL)
M961 1-763-072-11 FAN, D.C.
0 T971 1-435-325-11 POWER TRANSFORMER
************************************************************
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
**************
HARDWARE LIST
**************
#1 7-628-254-05 SCREW +PS 2.6X5
#2 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#3 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#4 7-685-650-79 SCREW +BVTP 3X16 TYPE2 N-S
#5 7-685-648-79 SCREW +BVTP 3X12 TYPE2 N-S
#6 7-685-881-09 SCREW +BVTT 4X8 (S)
#7 7-623-921-01 WASHER 1.7, NYLON
#8 7-685-783-09 SCREW +PTT 2X6 (S)
TRANS
Ver 1.1
