72
HCD-DZ100K/DZ500KF
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
I/O
C217 1-126-933-11 ELECT 100uF 20% 16V
C218 1-115-156-11 CERAMIC CHIP 1uF 10V
C219 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C220 1-126-964-11 ELECT 10uF 20% 50V
C221 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C222 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C223 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C224 1-126-916-11 ELECT 1000uF 20% 6.3V
C225 1-126-916-11 ELECT 1000uF 20% 6.3V
C226 1-126-916-11 ELECT 1000uF 20% 6.3V
C227 1-126-933-11 ELECT 100uF 20% 16V
C228 1-126-933-11 ELECT 100uF 20% 16V
C231 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C232 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C233 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C242 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C603 1-104-662-91 ELECT 22uF 20% 25V
C604 1-104-662-91 ELECT 22uF 20% 25V
C605 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C606 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C607 1-104-662-91 ELECT 22uF 20% 25V
C608 1-126-933-11 ELECT 100uF 20% 16V
C609 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C610 1-104-662-91 ELECT 22uF 20% 25V
C611 1-104-662-91 ELECT 22uF 20% 25V
C612 1-104-662-91 ELECT 22uF 20% 25V
C613 1-104-662-91 ELECT 22uF 20% 25V
C615 1-126-960-11 ELECT 1uF 20% 50V
C616 1-126-960-11 ELECT 1uF 20% 50V
C619 1-104-662-91 ELECT 22uF 20% 25V
C620 1-104-662-91 ELECT 22uF 20% 25V
C622 1-104-662-91 ELECT 22uF 20% 25V
C625 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C626 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C630 1-104-662-91 ELECT 22uF 20% 25V
C645 1-130-491-00 MYLAR 0.047uF 5% 50V
C649 1-126-933-11 ELECT 100uF 20% 16V
C650 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C654 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C655 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C656 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C657 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C662 1-126-933-11 ELECT 100uF 20% 16V
C663 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C664 1-124-464-11 ELECT 0.22uF 20% 50V
C665 1-104-662-91 ELECT 22uF 20% 25V
C666 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C669 1-126-933-11 ELECT 100uF 20% 16V
C670 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN101 1-568-828-11 CONNECTOR, FFC 9P
CN201 1-779-281-11 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
CN601 1-779-291-11 CONNECTOR, FFC (LIF (NON-ZIF)) 23P
* CN602 1-568-942-11 PIN, CONNECTOR 4P
CN603 1-564-707-11 PIN, CONNECTOR (SMALL TYPE) 5P
< IC >
IC201 6-705-602-01 IC MM1623BFBE
IC203 8-759-696-10 IC NJM2235V (TE2)
IC204 8-759-284-49 IC NJM2285V-TE2
IC601 8-759-385-76 IC MC14052 BDR2
IC602 8-759-649-89 IC MC4558CD
IC606 8-759-649-89 IC MC4558CD
IC607 6-706-078-01 IC M62429FP-TP
< JACK >
J201 1-780-211-11 TERMINAL BOARD (S TERMINAL+1P)
(MONITOR OUT)
J202 1-817-449-11 JACK, PIN 3P (COMPONENT VIDEO OUT)
J601 1-764-592-11 JACK 3P (VIDEO)
< COIL >
L101 1-469-525-91 INDUCTOR 10uH
L201 1-469-525-91 INDUCTOR 10uH
L202 1-469-525-91 INDUCTOR 10uH
L602 1-469-525-91 INDUCTOR 10uH
L603 1-469-525-91 INDUCTOR 10uH
< TRANSISTOR >
Q601 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q602 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q603 8-729-901-00 TRANSISTOR DTC124EK
Q604 8-729-901-00 TRANSISTOR DTC124EK
Q605 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q606 8-729-901-00 TRANSISTOR DTC124EK
Q607 8-729-901-00 TRANSISTOR DTC124EK
Q608 8-729-901-00 TRANSISTOR DTC124EK
Q609 8-729-901-00 TRANSISTOR DTC124EK
< RESISTOR >
R102 1-216-864-11 SHORT CHIP 0
R105 1-216-845-11 METAL CHIP 100K 5% 1/10W
R109 1-216-864-11 SHORT CHIP 0
R114 1-216-864-11 SHORT CHIP 0
R115 1-216-845-11 METAL CHIP 100K 5% 1/10W
R116 1-216-845-11 METAL CHIP 100K 5% 1/10W
R117 1-216-845-11 METAL CHIP 100K 5% 1/10W
R202 1-218-285-11 METAL CHIP 75 5% 1/10W
R203 1-216-864-11 SHORT CHIP 0
R204 1-216-821-11 METAL CHIP 1K 5% 1/10W
R205 1-216-864-11 SHORT CHIP 0
R206 1-216-864-11 SHORT CHIP 0
R207 1-216-864-11 SHORT CHIP 0
R209 1-216-864-11 SHORT CHIP 0
R226 1-216-864-11 SHORT CHIP 0
R228 1-216-833-11 METAL CHIP 10K 5% 1/10W
R229 1-218-285-11 METAL CHIP 75 5% 1/10W
R230 1-218-285-11 METAL CHIP 75 5% 1/10W
R231 1-218-285-11 METAL CHIP 75 5% 1/10W
R232 1-218-285-11 METAL CHIP 75 5% 1/10W
R233 1-218-285-11 METAL CHIP 75 5% 1/10W
R241 1-218-285-11 METAL CHIP 75 5% 1/10W
R602 1-216-833-11 METAL CHIP 10K 5% 1/10W
R606 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
